COOLING ASSEMBLY для Arctic Cat ZR 6000 R SX GREEN - 2017 года выпуска
-
№АртикулНазвание
-
10713-220 EXCHANGER, HEAT - FRONTEXCHANGER, HEAT - FRONT
-
28060-706 RIVETRIVET
-
31623-251 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
48060-702 RIVETRIVET
-
50608-631 PLATE, RETAININGPLATE, RETAINING
-
68060-708 RIVETRIVET
-
70610-692 HOSE - GREEN - 25 FTHOSE - GREEN - 25 FT
-
70610-693 HOSE - GREEN - 100 FTHOSE - GREEN - 100 FT
-
81623-655 CLAMP, HOSECLAMP, HOSE
-
90610-538 HOSE - 25 FTHOSE - 25 FT
-
100610-717 FITTING, DOUBLE-TFITTING, DOUBLE-T
-
110623-063 CLAMP, HOSECLAMP, HOSE
-
120123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
130613-258 HOSE, COOLANT - ENGINE TO FRONT EXCHANGERHOSE, COOLANT - ENGINE TO FRONT EXCHANGER
-
140619-619 CONDUIT, FLEXIBLE - 4 IN.CONDUIT, FLEXIBLE - 4 IN.
-
151623-656 CLAMP, HOSECLAMP, HOSE
-
162623-088 CLAMP, HOSECLAMP, HOSE
-
170613-122 HOSE, COOLANT - FRONT/REAR HEAT EXCHANGERHOSE, COOLANT - FRONT/REAR HEAT EXCHANGER
-
180613-113 EXCHANGER, HEAT - REAREXCHANGER, HEAT - REAR
-
190613-256 HOSE, COOLANT - REAR HEAT EXCHANGER/COOLANT JUNCTIONHOSE, COOLANT - REAR HEAT EXCHANGER/COOLANT JUNCTION
-
200613-228 FITTINGFITTING
-
210613-234 HOSE, COOLANT - TANK/ENGINEHOSE, COOLANT - TANK/ENGINE
-
222606-284 CAPCAP
-
230613-254 HOSE, COOLANT - FILLER NECK/COOLANT JUNCTIONHOSE, COOLANT - FILLER NECK/COOLANT JUNCTION
-
240423-317 CLAMPCLAMP
-
250613-030 NECK, FILLERNECK, FILLER
