01- Cooling System для BRP Lynx 49 Ranger 600 E-TEC - 2012
-
№АртикулНазвание
-
1509000678 Engine Outlet HoseEngine Outlet Hose
-
2509000443 Aba Gear ClampAba Gear Clamp
-
3509000499 Thermostat HousingThermostat Housing
-
4509000760 RADIATOR HOSERADIATOR HOSE
-
5293650084 Norma ClampNorma Clamp
-
6509000443 Aba Gear ClampAba Gear Clamp
-
7414115200 Tie-Rap 180 mmTie-Rap 180 mm
-
8293650099 Oetiker Gear ClampOetiker Gear Clamp
-
9509000761 HOSE THERMOSTAT-JUNCTIONHOSE THERMOSTAT-JUNCTION
-
10509000672 Bypass HoseBypass Hose
-
11509000589 Return Radiator HoseReturn Radiator Hose
-
12509000372 T-FittingT-Fitting
-
13509000675 Radiator HoseRadiator Hose
-
14509000676 Filling HoseFilling Hose
-
15509000442 Gear ClampGear Clamp
-
16509000741 Bleeder HoseBleeder Hose
-
17293650046 Oetiker ClampOetiker Clamp
-
18293710059 Y-FittingY-Fitting
-
19415129508 Bleeder HoseBleeder Hose
-
20415080000 Tubing 16 mmTubing 16 mm
-
21513033231 Protector Tube, 16 mmProtector Tube, 16 mm
-
22509000368 Coolant TankCoolant Tank
-
23241151640 Hex. Flanged Screw K50 X 16Hex. Flanged Screw K50 X 16
-
24415110000 Polyurethane Hose 5.2 mmPolyurethane Hose 5.2 mm
-
25509000180 Pressure CapPressure Cap
-
26509000837 COOLING FANCOOLING FAN
-
27233261414 Hex. Flanged Elastic Nut M6Hex. Flanged Elastic Nut M6
-
28207661244 Hex. Flanged Screw M6 X 12Hex. Flanged Screw M6 X 12
-
29293720053 GrommetGrommet
-
30509000756 RadiatorRadiator
-
31509000746 RADIATOR SUPPORTRADIATOR SUPPORT
-
32605453745 BushingBushing
-
33207162544 Hex. Screw M6 X 25Hex. Screw M6 X 25
-
34234062410 Flat Washer 6 mmFlat Washer 6 mm
-
3520052 WASHER-LOCK DIN.127BWASHER-LOCK DIN.127B
-
36293650140 Oetiker ClampOetiker Clamp
-
37509000153 Check ValveCheck Valve
-
38509000407 Hose 8 mmHose 8 mm
-
39509000407 Hose 8 mmHose 8 mm
-
219700362 Antifreeze Bottle12X1Antifreeze Bottle12X1
