GEAR CHANGE MECHANISM для Kawasaki KFX400 (KSF400-A2) - 2004 года выпуска
-
№АртикулНазвание
-
1106511065-S002 CAP, OIL FILTERCAP, OIL FILTER
-
1310713107-S004 SHAFT, OIL PUMP IDLE GEARSHAFT, OIL PUMP IDLE GEAR
-
1321613216-S012 GEAR-COMP, OIL PUMPGEAR-COMP, OIL PUMP
-
1600716007-S006 SEAT-SPRINGSEAT-SPRING
-
1608216082-S004 PUMP-ASSY-OILPUMP-ASSY-OIL
-
1615416154-S001 ROTOR-PUMPROTOR-PUMP
-
4906549065-S004 FILTER-OILFILTER-OIL
-
5201052010-S004 ELEMENT-OIL FILTERELEMENT-OIL FILTER
-
5905159051-S005 GEAR-SPUR, OIL PUMPGEAR-SPUR, OIL PUMP
-
9203392033-S001 RING-SNAPRING-SNAP
-
92033A92033-S023 RING-SNAPRING-SNAP
-
9204392043-S007 PIN, 4X15.8PIN, 4X15.8
-
9205592055-S005 RING-O, D=1.9RING-O, D=1.9
-
92055A92055-S010 RING-O, D=2.4RING-O, D=2.4
-
9214092140-S003 BALL, OIL CHECK VALVEBALL, OIL CHECK VALVE
-
9214592145-S004 SPRING, OIL FILTER CAPSPRING, OIL FILTER CAP
-
92145A92145-S090 SPRING, OIL CHECK VALVESPRING, OIL CHECK VALVE
-
9215392153-S001 BOLTBOLT
-
92153A92153-S067 BOLTBOLT
-
9217292172-S167 SCREW, OIL PUMPSCREW, OIL PUMP
-
9218092180-S001 SHIM, 10X18X0.5SHIM, 10X18X0.5
