GENERATOR для Kawasaki KX 250 - 2003 года выпуска
-
№АртикулНазвание
-
132132G0610 BOLT, FLANGED, SMALLBOLT, FLANGED, SMALL
-
235235B0616 SCREW, PAN, WP, CROSSCREW, PAN, WP, CROS
-
2100321003-1400 STATORSTATOR
-
2100721007-1424 ROTOR, I=4.5 (OPT)ROTOR, I=4.5 (OPT)
-
21007A21007-1425 ROTOR, I=4.0ROTOR, I=4.0
-
21007B21007-1426 ROTOR, I=5.3 (OPT)ROTOR, I=5.3 (OPT)
-
21007C21007-1427 ROTOR, I=5.6 (OPT)ROTOR, I=5.6 (OPT)
-
21007D21007-1428 ROTOR, I=5.9 (OPT)ROTOR, I=5.9 (OPT)
-
21007E21007-1429 ROTOR, I=4.9 (OPT)ROTOR, I=4.9 (OPT)
-
2106621066-1123 REGULATOR, VOLTAGEREGULATOR, VOLTAGE
-
2111921119-1619 IGNITERIGNITER
-
2603026030-1962 HARNESSHARNESS
-
9201592015-1156 NUT, FLANGED, 12MMNUT, FLANGED, 12MM
-
9203892038-001 KEY, WOODRUFFKEY, WOODRUFF
-
9207592075-1138 DAMPER, 8MMDAMPER, 8MM
-
9215292152-1421 COLLAR, IGNITERCOLLAR, IGNITER
-
9215392153-0023 BOLT, 6X20BOLT, 6X20
