OIL PUMP для Kawasaki KLR250 - 2005 года выпуска
-
№АртикулНазвание
-
132132J0620 BOLT, FLANGED, SMALLBOLT, FLANGED, SMALL
-
220220B0614 SCREW, PAN, CROS, 6X14SCREW, PAN, CROS, 6X14
-
220A220B0625 SCREW, PAN, CROS, 6X25SCREW, PAN, CROS, 6X25
-
551551A0608 PIN, DOWEL, 6X8PIN, DOWEL, 6X8
-
671671B2555 O-RING, 55MMO-RING, 55MM
-
1101211012-1538 CAP, OIL FILTERCAP, OIL FILTER
-
1106011060-1130 GASKET, OIL PUMPGASKET, OIL PUMP
-
1321613216-1092 GEAR, COMP, OIL PUMPGEAR, COMP, OIL PUMP
-
1608216082-1080 PUMP, ASSY, OILPUMP, ASSY, OIL
-
1609716097-1001 FILTER, ASSY, OILFILTER, ASSY, OIL
-
1609916099-004 ELEMENT, OIL FILTERELEMENT, OIL FILTER
-
1614216142-1056 COVER, PUMPCOVER, PUMP
-
1615416154-1008 ROTOR, PUMPROTOR, PUMP
-
1615616156-002 PISTON, ASSY, VALVE, BY, PASSPISTON, ASSY, VALVE, BY, PASS
-
1616016160-1069 BODY, OIL PUMPBODY, OIL PUMP
-
9204292042-041 PIN, DOWEL, 4X12.8PIN, DOWEL, 4X12.8
-
9204392043-123 PIN, SPRING, 2.2X13.5PIN, SPRING, 2.2X13.5
-
9207192071-100 GROMMET, OIL STRAINERGROMMET, OIL STRAINER
-
92071A92071-101 GROMMET, OIL FILTERGROMMET, OIL FILTER
-
9208192081-043 SPRING, PISTONSPRING, PISTON
-
9213692136-002 VALVEVALVE
