FRONT FORK для Kawasaki Z1000 - 2005 года выпуска
-
№АртикулНазвание
-
1101211012-1761 CAPCAP
-
1106511065-0011 CAPCAP
-
44008A44008-1059 PIPE, FORK OUTER, GOLDPIPE, FORK OUTER, GOLD
-
4401344013-1513-D3 PIPE, FORK INNER (LEFT) (M.M.GOLD)PIPE, FORK INNER (LEFT) (M.M.GOLD)
-
44013A44013-1514-D3 PIPE, FORK INNER (RIGHT) (M.M.GOLD)PIPE, FORK INNER (RIGHT) (M.M.GOLD)
-
4402344023-0002 CYLINDER, SET, FORK (RIGHT)CYLINDER, SET, FORK (RIGHT)
-
44023A44023-0003 CYLINDER, SET, FORK (LEFT)CYLINDER, SET, FORK (LEFT)
-
4402644026-0004 SPRING, FRONT FORKSPRING, FRONT FORK
-
4402844028-1083 GUIDE, FORK SPRINGGUIDE, FORK SPRING
-
4403744037-1444 HOLDER, FORK UNDERHOLDER, FORK UNDER
-
4403944039-0020 HOLDER, FORK UPPERHOLDER, FORK UPPER
-
4404544045-051 GASKET, FORK CYLINDER BOLTGASKET, FORK CYLINDER BOLT
-
4406544065-0001 BUSHING, FRONT FORK, GUIDEBUSHING, FRONT FORK, GUIDE
-
44065A44065-0002 BUSHING, FRONT FORK, SLIDEBUSHING, FRONT FORK, SLIDE
-
4407544075-0018-D3 DAMPER, SET, FORK (M.M.GOLD)DAMPER, SET, FORK (M.M.GOLD)
-
5603056030-0006 LABELLABEL
-
9202292022-1713 WASHER, SPRING SEATWASHER, SPRING SEAT
-
9202692026-1276 SPACER, FORK OUTERSPACER, FORK OUTER
-
9203392033-0002 RING, SNAPRING, SNAP
-
92033A92033-1222 RING, SNAPRING, SNAP
-
9204992049-1363 SEAL, OIL, FORKSEAL, OIL, FORK
-
9205592055-0003 O-RINGO-RING
-
92055A92055-1497 O-RING, FORK CAPO-RING, FORK CAP
-
92055B92055-1498 O-RING, FORK VALVEO-RING, FORK VALVE
-
9206692066-0032 PLUGPLUG
-
9209292092-1090 BUSHING, RUBBERBUSHING, RUBBER
-
9209392093-1268 SEAL, FORKSEAL, FORK
-
9215292152-0011 COLLAR, SPRING, L=30COLLAR, SPRING, L=30
-
92152A92152-0012 COLLAR, SPRING, L=47.5COLLAR, SPRING, L=47.5
-
9215392153-0028 BOLT, SOCKET, 8X22BOLT, SOCKET, 8X22
-
92153A92153-0536 BOLT, SOCKET, 8X40BOLT, SOCKET, 8X40
-
92153B92153-0537 BOLT, SOCKETBOLT, SOCKET
-
92153C92153-0538 BOLT, SOCKETBOLT, SOCKET
-
9216192161-0006 DAMPERDAMPER
-
9220092200-1464 WASHERWASHER
-
9221092210-0019 NUTNUT
-
92210A92210-0020 NUT, SPRING ADJUSTERNUT, SPRING ADJUSTER
