METER(S) для Kawasaki Vulcan 800 Drifter - 2006 года выпуска
-
№АртикулНазвание
-
1327013270-1637 PLATE, PILOT LAMPPLATE, PILOT LAMP
-
2300823008-1546 SOCKET, ASSY, PILOT LAMPSOCKET, ASSY, PILOT LAMP
-
23008A23008-1604 SOCKET, ASSY, SPEEDOMETERSOCKET, ASSY, SPEEDOMETER
-
2302623026-1171 LENS (GREEN)LENS (GREEN)
-
23026A23026-1173 LENS, REDLENS, RED
-
2500525005-1724 SPEEDOMETER, MPHSPEEDOMETER, MPH
-
9200992009-1690 SCREW, 4X6SCREW, 4X6
-
92009A92009-1799 SCREW, 3X8SCREW, 3X8
-
9202292022-1949 WASHER, 4.3X12.5X1WASHER, 4.3X12.5X1
-
9206992069-1007 BULB, 12V 3.4W, T10BULB, 12V 3.4W, T10
-
92069A92069-1059 BULB, 12V 1.7W, T10BULB, 12V 1.7W, T10
-
92069B92069-1068 BULB, 12V 3W, T6.5BULB, 12V 3W, T6.5
-
92069C92069-1070 BULB, 12V 1.7W, T6.5BULB, 12V 1.7W, T6.5
-
9207792077-1117 KNOB, TRIPKNOB, TRIP
-
9215192151-1449 BOLT, SOCKET, 6X10BOLT, SOCKET, 6X10
-
9216092160-1068 DAMPERDAMPER
-
92160A92160-1380 DAMPER, SHOCK, METERDAMPER, SHOCK, METER
-
9220092200-1465 WASHER, 6.2X10X1WASHER, 6.2X10X1
Все узлы модели:
- AIR CLEANER
- BRAKE - FRONT
- BRAKE - MASTER CYLINDER - FRONT
- BRAKE - MASTER CYLINDER - REAR
- BRAKE - REAR
- BRAKE PEDAL W/ TORQUE LINK
- CABLES
- CAMSHAFT(S) W/ TENSIONER
- CARBURETOR
- CHASSIS ELECTRICAL EQUIPMENT
- CLUTCH
- CRANKCASE
- CRANKCASE BOLT PATTERN
- CRANKSHAFT
- CYLINDER HEAD
- CYLINDER HEAD COVER
- CYLINDER/PISTON(S)
- DECALS
- ENGINE COVER(S) - LEFT
- ENGINE COVER(S) - RIGHT
- ENGINE MOUNT
- FENDER(S)
- FOOTRESTS
- FRAME
- FRAME FITTINGS
- FRONT FORK
- FUEL EVAPORATIVE SYSTEM (CALIF ONLY)
- FUEL TANK
- GEAR CHANGE DRUM W/ SHIFT FORK(S)
- GEAR CHANGE MECHANISM
- GENERATOR
- HANDLEBAR
- HEADLIGHT(S)
- IGNITION SWITCH W/ LOCKS AND REFLECTORS
- IGNITION SYSTEM
- LABELS
- MANUALS
- • METER(S)
- MUFFLER(S)
- OIL PUMP/OIL FILTER
- OWNERS TOOLS
- RADIATOR
- SEAT
- SEAT - FRONT
- SIDE COVERS W/ CHAIN COVER
- STAND(S)
- STARTER MOTOR
- SUSPENSION - REAR W/ SHOCK ABSORBER
- SUSPENSION - SWINGARM
- TAILLIGHT(S)
- TIRES
- TRANSMISSION
- TURN SIGNALS
- VALVE(S)
- WHEEL - FRONT
- WHEEL - REAR W/ CHAIN
