CYLINDER HEAD для Kawasaki NINJA ZX-10R (ZX1000JFF) - 2015 года выпуска
-
№АртикулНазвание
-
120120CD0630 BOLT-SOCKET,6X30BOLT-SOCKET,6X30
-
1100411004-0094 GASKET-HEADGASKET-HEAD
-
1100811008-0721 HEAD-COMP-CYLINDERHEAD-COMP-CYLINDER
-
1606516065-0115 HOLDER-CARBURETORHOLDER-CARBURETOR
-
4900249002-0009 GUIDE-VALVEGUIDE-VALVE
-
9200492004-0049 STUD,8X18STUD,8X18
-
9204292042-007 PIN,DOWEL,6.3X8X14PIN,DOWEL,6.3X8X14
-
9204392043-1264 PIN,8.2X10X14PIN,8.2X10X14
-
9205592055-1600 RING-O,47X1.9RING-O,47X1.9
-
9206692066-0016 PLUG,18X10PLUG,18X10
-
9215392153-0454 BOLT,TORX,6X18BOLT,TORX,6X18
-
92153A92153-0656 BOLT,SOCKET,6X45BOLT,SOCKET,6X45
-
92153B92153-0893 BOLT,FLANGED,10X90BOLT,FLANGED,10X90
-
9217392173-0222 CLAMPCLAMP
-
9220092200-0114 WASHER,10.5X19X2.3WASHER,10.5X19X2.3
