GEAR CHANGE MECHANISM для Kawasaki NINJA ZX-10R (ZX1000JFF) - 2015 года выпуска
-
№АртикулНазвание
-
480480J1400 CIRCLIP-TYPE-C,14MMCIRCLIP-TYPE-C,14MM
-
1307813078-0012 RATCHETRATCHET
-
1316113161-0078 LEVER-COMP-CHANGE SHAFTLEVER-COMP-CHANGE SHAFT
-
1316513165-0018 PAWLPAWL
-
1323613236-0191 LEVER-COMP,CHANGE PEDALLEVER-COMP,CHANGE PEDAL
-
13236A13236-0192 LEVER-COMP,POSITIONLEVER-COMP,POSITION
-
1324213242-0066 LEVER-ASSY-CHANGELEVER-ASSY-CHANGE
-
1327213272-1175 PLATEPLATE
-
3911139111-0080 ROD-TIEROD-TIE
-
9202292022-1827 WASHER,6X12.8X1.2WASHER,6X12.8X1.2
-
92022A92022-272 WASHER,14.3X24X1WASHER,14.3X24X1
-
9204392043-1676 PIN,PLUNGERPIN,PLUNGER
-
9214592145-0786 SPRINGSPRING
-
92145A92145-0849 SPRINGSPRING
-
92145B92145-1490 SPRINGSPRING
-
9215092150-1673 BOLT,SOCKET,6X16BOLT,SOCKET,6X16
-
92150A92150-1869 BOLT, RETURN SPRINGBOLT, RETURN SPRING
-
9215192151-1226 BOLT,FLANGED,6X20BOLT,FLANGED,6X20
-
9215292152-1414 COLLARCOLLAR
-
9215392153-1669 BOLT,TORX,6X8.7BOLT,TORX,6X8.7
-
9215492154-0399 BOLTBOLT
-
9216192161-0871 DAMPERDAMPER
-
9220092200-0265 WASHERWASHER
-
92200A92200-0810 WASHER,8.2X30X1.5WASHER,8.2X30X1.5
-
92200B92200-0811 WASHER,8.2X18X1.2WASHER,8.2X18X1.2
-
92200C92200-0812 WASHER,18.3X30X1WASHER,18.3X30X1
-
9221092210-1100 NUT,6MMNUT,6MM
-
92210A92210-1101 NUT, LEFT HANDED,6MMNUT, LEFT HANDED,6MM
