SIDE AND CENTERSTAND для Ktm 200 MXC - 2001 года выпуска
-
№АртикулНазвание
-
2150303023060 SCREW M8 SIDE STANDSCREW M8 SIDE STAND
-
2250303023160 SCREW M8 SIDE STANDSCREW M8 SIDE STAND
-
2350303023000 SIDE STAND L=377MMSIDE STAND L=377MM
-
2450303023052 BOLT SIDE ST..SPRING M5BOLT SIDE ST..SPRING M5
-
2550303023152 BOLT SIDE ST.SPRING M5BOLT SIDE ST.SPRING M5
-
2650303026000 SIDE ST.BRACKET CPL.SIDE ST.BRACKET CPL.
-
2850303023054 BRACKET FOR SPRINGBRACKET FOR SPRING
-
2950303025000 RUBBER FOR SIDE STANDRUBBER FOR SIDE STAND
-
3050303024000 SIDESTAND SPRINGSIDESTAND SPRING
-
3110003021000 STAND SPRING SHORTSTAND SPRING SHORT
-
5958429059000 LOCTITE 648 GREEN 20MLLOCTITE 648 GREEN 20ML
-
606899785 LOCTITE 243 BLUE 6CCMLOCTITE 243 BLUE 6CCM
-
8654310086200 SELF LOCKING NUT M8 10.9SELF LOCKING NUT M8 10.9
Все узлы модели:
- ACCESSORIES
- AIR FILTER BOX
- BRAKE CALIPER FRONT
- BRAKE CALIPER REAR
- CARBURETOR KEIHIN PWK39/38AG
- CLUTCH
- CLUTCH COVER
- CLUTCH COVER WITH OILPUMP
- COOLING SYSTEM
- CRANKSHAFT W/ PISTON
- CYLINDER
- DECAL
- ENGINE CASE
- ENGINE CASE WITH OILPUMP - LEFT
- EXHAUST PIPE
- EXHAUST SILENCER
- FLASHER - REAR LIGHT
- FORK LEGS
- FRAME - SUB FRAME
- FRESH OIL LUBRICATION
- FRONT FORK
- FRONT WHEEL
- HAND BRAKE CYLINDER
- HANDLEBAR W/ CONTROLS
- HEAD LIGHT
- IGNITION SYSTEM
- KICKSTARTER
- MASK W/ FENDERS
- REAR BRAKE CONTROL
- REAR WHEEL
- REED VALVE CASE
- REED VALVE CASE FOR OILPUMP
- SHIFTING MECHANISM
- SHOCK ABSORBER
- • SIDE AND CENTERSTAND
- SPECIAL TOOLS
- SPEEDOMETER FACOMSA
- SPEEDOMETER ODOMETER
- SPEEDOMETER SIGMA SPORT
- SWINGARM W/ CHAIN GUARD
- TANK - SEAT - COVERS
- TRANSMISSION - COUNTERSHAFT
- TRANSMISSION - MAIN SHAFT
- TWIN VALVE CONTROL
- WIRING HARNESS SEPERATE LUBRICATION
