FRONT WHEEL для Ktm 85 SX - 2005 года выпуска
-
№АртикулНазвание
-
147009001044 FRONT WHEEL SP 17"FRONT WHEEL SP 17"
-
147009001144 FRONT WHEEL SP 19"FRONT WHEEL SP 19"
-
104700901004496 FRONT WHEEL HUB CPLFRONT WHEEL HUB CPL
-
1147009011000 BEARING SPACER TUBEBEARING SPACER TUBE
-
1247009012000 SPACER BUSHINGSPACER BUSHING
-
130760253572 SEAL SHAFT RING 25X35X7 BSLSEAL SHAFT RING 25X35X7 BSL
-
140625060037 GR.BALL BEAR. 6003-2RSH/C3HMTFGR.BALL BEAR. 6003-2RSH/C3HMTF
-
5559009062013 SPECIAL SCREW M6X13 WS=8 10.9SPECIAL SCREW M6X13 WS=8 10.9
-
6047009060000 BRAKE DISC FRONT D=220MMBRAKE DISC FRONT D=220MM
-
7047009070000 RIM FRONT AL4 17X1,40-32RIM FRONT AL4 17X1,40-32
-
7047009070100 RIM FRONT AL4 19X1,60-32RIM FRONT AL4 19X1,60-32
-
7247009072186 SPOKE FRONT 17" 4/3,5/4-186SPOKE FRONT 17" 4/3,5/4-186
-
7247009072210 SPOKE FRONT 19" 4/3,5/4-210SPOKE FRONT 19" 4/3,5/4-210
-
7350309012000 SPOKE NIPPLE M4,5X0,75 8X21SPOKE NIPPLE M4,5X0,75 8X21
-
7447009073000 RIM BAND 17"RIM BAND 17"
-
7447009073100 RIM BAND 19"RIM BAND 19"
-
8147009081000 AXLE FRONTAXLE FRONT
-
8349032011000 HH COLLAR SCREW M10X20 WS=17HH COLLAR SCREW M10X20 WS=17
-
8655009086000 PLUG SFL13PLUG SFL13
-
8955003135000 PLUG FOR RIMPLUG FOR RIM
-
9050310090050 NUT FOR WHEEL HOLDERNUT FOR WHEEL HOLDER
-
9151009100100 RIM LOCK VM1 (1,60") (ONLY FOR 19" WHEEL)RIM LOCK VM1 (1,60") (ONLY FOR 19" WHEEL)
