LUBRICATING SYSTEM для Ktm 990 SUPERMOTO-R - 2010 года выпуска
-
№АртикулНазвание
-
162638081033 OIL TANK CPL.OIL TANK CPL.
-
258030020100 PLUG CPL. M24X3PLUG CPL. M24X3
-
30770191015 O-RING 19,00X3,00 NBRO-RING 19,00X3,00 NBR
-
462638081060 PIPE FITTINGPIPE FITTING
-
559030022100 BLEEDER FLANGE M12X1,5 WS=13BLEEDER FLANGE M12X1,5 WS=13
-
858030021000 OILDRAIN PLUG W.MAG. M 12X1,5OILDRAIN PLUG W.MAG. M 12X1,5
-
958038022000 CU-SEAL RING DIN7603-12X18X1,5CU-SEAL RING DIN7603-12X18X1,5
-
1062538034030 PREFORMED HOSE 9X15PREFORMED HOSE 9X15
-
1162638060000 SUCTION PIPE CPLSUCTION PIPE CPL
-
120770090021 O-RING 9X2 VITONO-RING 9X2 VITON
-
130770110020 O-RING 11,00X2,00 VITONO-RING 11,00X2,00 VITON
-
1462638061000 RETURN OIL LINE CPLRETURN OIL LINE CPL
-
1600050170706 VARIABLE ONE-EAR CLAMP 17,0MMVARIABLE ONE-EAR CLAMP 17,0MM
-
1860038017000 OIL SCREEN FINISHEDOIL SCREEN FINISHED
-
1960038018000 GASKET FOR OIL FILTER HNBRGASKET FOR OIL FILTER HNBR
-
2060038024000 PLUG 10MM LC8PLUG 10MM LC8
-
210770110021 O-RING 11X2 VITONO-RING 11X2 VITON
-
2260038037000 RETAINING PLATE 2 LC8RETAINING PLATE 2 LC8
-
2360038036000 RETAINING PLATE 1 LC8RETAINING PLATE 1 LC8
-
240912060163 AH SCREW DIN0912-M 6X16AH SCREW DIN0912-M 6X16
-
2560038083000 SCREW OIL TANK FIXINGSCREW OIL TANK FIXING
-
260019050121 COUNTERSUNK SCREW ISA25 M5X12COUNTERSUNK SCREW ISA25 M5X12
-
2762638084044 OIL SIGHT GLASS CPL.OIL SIGHT GLASS CPL.
-
3700049160121 CLAMP STD DN16CLAMP STD DN16
-
4060038010133 PRESSURE PUMP HOUSING CPL.PRESSURE PUMP HOUSING CPL.
-
4160038026000 CONTROL SPRING LC8 3,5 BARCONTROL SPRING LC8 3,5 BAR
-
4260038028000 CONTROL PISTON LC8CONTROL PISTON LC8
-
4350337073000 SHIMSHIM
-
4560038011000 ROTOR-SET PRESSURE PUMPROTOR-SET PRESSURE PUMP
-
4660038002000 OIL PUMP SHAFTOIL PUMP SHAFT
-
470402041580 NEEDLE ROLLER NRB 4X15,8 G2NEEDLE ROLLER NRB 4X15,8 G2
-
4860038001124 OIL PUMP GEAR 24-TOIL PUMP GEAR 24-T
-
490799080000 TAB WASHER DIN6799 RS8TAB WASHER DIN6799 RS8
-
5060038007010 WASHER 10X16X0,5WASHER 10X16X0,5
-
5160038009000 ROTOR-SET 19MMROTOR-SET 19MM
-
5260038008000 SUCTION PUMP CASESUCTION PUMP CASE
-
530402040980 NEEDLE ROL.DIN5402 NRB 4X9,8NEEDLE ROL.DIN5402 NRB 4X9,8
-
540770133024 O-RING 13,3X2,4 VITONO-RING 13,3X2,4 VITON
-
5560038016000 OIL SCREENOIL SCREEN
-
560025060406 HH COLLAR SCREW M6X40 TX30HH COLLAR SCREW M6X40 TX30
-
570025060256 HH COLLAR SCREW M6X25 TX30HH COLLAR SCREW M6X25 TX30
-
590770010010 O-RING 10,00X1,00 NBR 70 SHO-RING 10,00X1,00 NBR 70 SH
-
6060030065100 OIL INJECTION TUBE GEAROIL INJECTION TUBE GEAR
-
6160038015000 OIL FILTEROIL FILTER
-
620025060166 HH COLLAR SCREW M6X16 TX30HH COLLAR SCREW M6X16 TX30
