CHOKE PLATE AND THROTTLE LEVERS(S/N-C239553 AND UP) для Mariner - V-200 0C100861 THRU 0C291519
-
№АртикулНазвание
-
1817495A1 COVER, SOUND ATTENUATORCOVER, SOUND ATTENUATOR
-
210-92051 SCREW, (10-16 x .75)SCREW, (10-16 x .75)
-
327-188891 GASKET, SOUND ATTENUATORGASKET, SOUND ATTENUATOR
-
4817495A1 PLATE, Sound AttenuatorPLATE, Sound Attenuator
-
527-892211 GASKET, PLATE TO CARBURETORGASKET, PLATE TO CARBURETOR
-
610-68000 SCREW, (.250-28 x 1.00), SOUND ATTENUATORSCREW, (.250-28 x 1.00), SOUND ATTENUATOR
-
712-20583 WASHER, SOUND ATTENUATOR SCREWWASHER, SOUND ATTENUATOR SCREW
-
821-64871A2 CHECK VALVECHECK VALVE
-
922-15026 CAPCAP
-
1087604 LINK, ThrottleLINK, Throttle
-
11828277A1 LEVER ASSEMBLY, ThrottleLEVER ASSEMBLY, Throttle
-
12828277A1 LEVER, ThrottleLEVER, Throttle
-
1367748 ROLLER, LOWER THROTTLE LEVERROLLER, LOWER THROTTLE LEVER
-
1410-15124 SCREW, (#10-32 x .750), THROTTLE LEVERS TO THROTTLE LINKSCREW, (#10-32 x .750), THROTTLE LEVERS TO THROTTLE LINK
-
1513-26996 LOCKWASHER, (#10) Stainless Steel, THROTTLE LEVERS SCREWLOCKWASHER, (#10) Stainless Steel, THROTTLE LEVERS SCREW
-
1612-56681 WASHER, (.203 x .500 x .032), THROTTLE LEVERS SCREWWASHER, (.203 x .500 x .032), THROTTLE LEVERS SCREW
-
1717-67297 PIN, Clevis, THROTTLE LEVERS TO THROTTLE LINKPIN, Clevis, THROTTLE LEVERS TO THROTTLE LINK
-
1812-89302 WASHER, (.203 x .406 x .040), CLEVIS PINWASHER, (.203 x .406 x .040), CLEVIS PIN
-
1918-26953 COTTER PIN, CLEVIS PINCOTTER PIN, CLEVIS PIN
