CAMSHAFT W/ VALVE ASSY. для Polaris SCRABMLER 500 (A00BG50AA) - 2000 года выпуска
-
№АртикулНазвание
-
13084845 PLUGPLUG
-
23084920 GASKET, PLUGGASKET, PLUG
-
33086839 SPRING, TENSIONERSPRING, TENSIONER
-
43086813 TENSIONER ASSY. (INCL. 1-3)TENSIONER ASSY. (INCL. 1-3)
-
53084922 GASKET, TENSIONERGASKET, TENSIONER
-
63084910 ROCKERARM ASSY. INTAKE (INCL. 8,9)ROCKERARM ASSY. INTAKE (INCL. 8,9)
-
73084913 ROCKERARM ASSY. EXHAUST (INCL. 8,9)ROCKERARM ASSY. EXHAUST (INCL. 8,9)
-
83084912 NUTNUT
-
93084911 SCREW, ADJUSTERSCREW, ADJUSTER
-
103084909 SHAFT, ROCKERSHAFT, ROCKER
-
113084908 COLLET, VALVECOLLET, VALVE
-
123084907 RETAINER, VALVE SPRINGRETAINER, VALVE SPRING
-
133084906 SPRING VALVESPRING VALVE
-
143085855 CAMSHAFT (INCL. 15-18)CAMSHAFT (INCL. 15-18)
-
153086838 DOWEL, PINDOWEL, PIN
-
163085348 LEVER, RELEASELEVER, RELEASE
-
173085076 SPRING, RETURNSPRING, RETURN
-
183084899 PIN, DOWELPIN, DOWEL
-
193084914 SPROCKETSPROCKET
-
203081657 BOLT AND WASHER ASSY.BOLT AND WASHER ASSY.
-
213084916 GUIDE, CHAINGUIDE, CHAIN
-
223084915 CHAIN, TIMINGCHAIN, TIMING
-
233084924 BOLT, PIVOT LEVERBOLT, PIVOT LEVER
-
243084917 LEVERLEVER
-
253085349 VALVE, INTAKEVALVE, INTAKE
-
263084905 VALVE, EXHAUSTVALVE, EXHAUST
-
273084874 BOLT, FLANGEBOLT, FLANGE
