COOLING SYSTEM для Polaris XPLORER 400 (A01CG38CA) - 2001 года выпуска
-
№АртикулНазвание
-
17517659 SCREWSCREW
-
22410123 FAN AND MOTOR, ASSY. SPALFAN AND MOTOR, ASSY. SPAL
-
37670111 CLIPCLIP
-
45434043 SHROUD, FANSHROUD, FAN
-
55020572 SPACER, MOUNTSPACER, MOUNT
-
63110032 MOUNT, RUBBERMOUNT, RUBBER
-
77547069 NUTSERT, HEXNUTSERT, HEX
-
87080614 CLAMP, HOSECLAMP, HOSE
-
95411986 HOSE, UPPER ENGINEHOSE, UPPER ENGINE
-
107080826 CLAMP, ROTO CLIPCLAMP, ROTO CLIP
-
114010161 SENSOR, THERMAL/HARNESSSENSOR, THERMAL/HARNESS
-
121240093 CAP, PRESSURECAP, PRESSURE
-
131240090 RADIATORRADIATOR
-
147558301 WASHERWASHER
-
157512240 BOLTBOLT
-
167552801 LOCK WASHERLOCK WASHER
-
177052296 VALVE, PLASTIC RAD/COOLER DRAINVALVE, PLASTIC RAD/COOLER DRAIN
-
185410584 BUSHING, MOUNT (LOW RED)BUSHING, MOUNT (LOW RED)
-
197080965 MOUNT, CABLE TIEMOUNT, CABLE TIE
-
207080138 STRAP, PANDUITSTRAP, PANDUIT
-
215521550 PLASTIC, HOSE GUARD 18''PLASTIC, HOSE GUARD 18''
-
225411989 HOSE, LOWER ENGINEHOSE, LOWER ENGINE
Все узлы модели:
- AIR BOX ASSY.
- BRAKE - FRONT
- BRAKE - MASTER CYLINDER W/ BRAKE LINE
- BRAKE - REAR CALIPER
- BRAKE - REAR MASTER CYLINDER
- CARBURETOR
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CLUTCH COVER
- • COOLING SYSTEM
- CRANKCASE W/ CYLINDER
- CV JOINT - NEAPCO
- DECALS
- DIFFERENTIAL - FRONT
- DRIVESHAFT - INTERMEDIATE
- ELECTRICAL W/ TAILLIGHT ASSY.
- EXHAUST SYSTEM
- FENDER - FRONT W/ SIDE PANELS
- FENDER - REAR W/ SEAT
- FUEL TANK
- GEAR SELECTOR
- GEARCASE - INTERNAL COMPONENTS (IF BUILT AFTER 4/01/01)
- GEARCASE - INTERNAL COMPONENTS (IF BUILT BOFORE 4/01/01)
- GEARCASE MOUNTING
- HANDLEBAR
- HANDLEBAR - THROTTLE ASSY. W/ CABLE
- HOUSING - REAR W/ AXLE
- MAGNETO
- MOUNTING - ENGINE
- OIL PUMP
- OIL TANK
- PISTON AND CRANKSHAFT
- RACK AND BUMPER MOUNTING - FRONT
- RACK AND BUMPER MOUNTING - REAR
- STARTER - RECOIL
- STARTING MOTOR
- STEERING POST
- SUSPENSION - FRONT A - ARM W/ TIE RODS
- SUSPENSION - FRONT STRUT
- SUSPENSION - REAR SWING ARM W/ SHOCK MOUNTING
- TOOL KIT
- WATER PUMP
- WHEEL - FRONT
- WHEEL - REAR
