DRIVESHAFT - FRONT для Polaris XPLORER 4X4 (A02CG25CA) - 2002 года выпуска
-
№АртикулНазвание
-
25222299 SLEEVE, SEALSLEEVE, SEAL
-
33260121 CLAMP, BANDCLAMP, BAND
-
47670092 CIRCLIP,DRIVESHAFT,NEAPCOCIRCLIP,DRIVESHAFT,NEAPCO
-
52201015 KIT,BOOT REPLACEMENTKIT,BOOT REPLACEMENT
-
61380060 SHAFT, WELD. (INCL. 4)SHAFT, WELD. (INCL. 4)
-
71380061 CARDAN WELD. (INCL. 4,6,8,9)CARDAN WELD. (INCL. 4,6,8,9)
-
83260104 KIT,CROSSANDBEARINGKIT,CROSSANDBEARING
-
93260101 YOKEYOKE
-
107661913 PIN,SPRINGPIN,SPRING
-
113260123 CLAMP, BANDCLAMP, BAND
-
122200960 KIT,DRIVESHAFT,W/SLV,NEAKIT,DRIVESHAFT,W/SLV,NEA
Все узлы модели:
- AIR BOX ASSY.
- BRAKE - FRONT
- BRAKE - MASTER CYLINDER W/ BRAKE LINE
- BRAKE - REAR
- BRAKE - REAR CALIPER
- CARBURETOR
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CLUTCH COVER
- COOLING SYSTEM
- CRANKCASE W/ CYLINDER
- CRANKSHAFT W/ PISTON
- DECALS
- DIFFERENTIAL - FRONT
- • DRIVESHAFT - FRONT
- DRIVESHAFT - FRONT INTERMEDIATE
- ELECTRICAL W/ TAILLIGHT ASSY.
- EXHAUST SYSTEM
- FENDER - FRONT W/ SIDE PANELS
- FENDER - REAR W/ SEAT
- FUEL TANK
- GEAR SELECTOR
- GEARCASE
- HANDLEBAR
- HANDLEBAR - THROTTLE ASSY. W/ CABLE
- HOUSING - REAR W/ AXLE
- MAGNETO
- MOUNTING - ENGINE
- OIL PUMP
- OIL TANK
- RACK AND BUMPER MOUNTING - FRONT
- STARTER - RECOIL
- STARTING MOTOR
- STEERING POST
- SUSPENSION - FRONT A - ARM W/ TIE RODS
- SUSPENSION - FRONT STRUT
- SUSPENSION - REAR SWING ARM W/ SHOCK MOUNTING
- TOOL KIT
- WHEEL - FRONT
- WHEEL - REAR
