FUEL TANK для Polaris ACE 500 SOHC [A18DAA50B7] - 2018 года выпуска
-
№АртикулНазвание
-
-2207669 FUEL PUMP,SERVICE KIT,ACE (INCL. PUMP, GASKET, NUT, INSTRUCTIONS)FUEL PUMP,SERVICE KIT,ACE (INCL. PUMP, GASKET, NUT, INSTRUCTIONS)
-
-2521693 ASM-FUEL PUMPASM-FUEL PUMP
-
12521691 ASM-FUEL TANKASM-FUEL TANK
-
22521899 ASM-FUEL LINE,RAILASM-FUEL LINE,RAIL
-
35439075 CAP-GAS TANKCAP-GAS TANK
-
47080499 CLAMP, CABLECLAMP, CABLE
-
57670116 CLIP, ROUTING, HINGEDCLIP, ROUTING, HINGED
-
68450040-600 FUEL LINEFUEL LINE
-
77081689 T-CLIP, T15T-CLIP, T15
-
87082038 STRAP, CABLE TIE W/EDGE CLIPSTRAP, CABLE TIE W/EDGE CLIP
-
97512024 SCREWSCREW
-
107518552 SCR-10-24X1 PN TRX TFS STL-YSCR-10-24X1 PN TRX TFS STL-Y
-
117519650 SCREWSCREW
-
125453464 FITTING-VENT LINE,90FITTING-VENT LINE,90
-
137080880 CLAMP-HOSE,.625 DIA VNL COATEDCLAMP-HOSE,.625 DIA VNL COATED
-
147518533 SCR-HXFL-M6X1.0X25 8.8 RIESCR-HXFL-M6X1.0X25 8.8 RIE
-
157547339 NUT-M6X1.0,FLG-NYLOC-OLIVE DNUT-M6X1.0,FLG-NYLOC-OLIVE D
-
167081871 CLIP-HARNESS 3-13MM INTERLCKCLIP-HARNESS 3-13MM INTERLCK
