PISTON AND CRANKSHAFT для Polaris 500 CLASSIC (S00SD4BS) - 2000 года выпуска
-
№АртикулНазвание
-
13083839 CLIP, PISTON PINCLIP, PISTON PIN
-
23084342 RING, PISTON (STD)RING, PISTON (STD)
-
23084343 RING, PISTON (0.25MM/.010''O/S) (OPT)RING, PISTON (0.25MM/.010''O/S) (OPT)
-
23084344 RING, PISTON (0.50MM/.020''O/S) (OPT)RING, PISTON (0.50MM/.020''O/S) (OPT)
-
33084339 PISTON (STD)PISTON (STD)
-
33084340 PISTON (0.25MM/.010''O/S) (OPT)PISTON (0.25MM/.010''O/S) (OPT)
-
33084341 PISTON (0.50MM/.020''O/S) (OPT)PISTON (0.50MM/.020''O/S) (OPT)
-
43083858 PIN, PISTONPIN, PISTON
-
53083277 SPACER, CRANKPINSPACER, CRANKPIN
-
63083456 PIN, CRANK 2 (57MM)PIN, CRANK 2 (57MM)
-
73085628 BEARING, LARGE ENDBEARING, LARGE END
-
83083252 ROD, CONNECTINGROD, CONNECTING
-
93083216 BEARING, SMALL ENDBEARING, SMALL END
-
103083233 PIN, CRANK (56MM)PIN, CRANK (56MM)
-
113085205 BALL, BEARINGBALL, BEARING
-
123085203 SPACERSPACER
-
133085204 BALL BEARINGBALL BEARING
-
143085202 CRANKSHAFT 3 (PTO)CRANKSHAFT 3 (PTO)
-
153081447 KEYKEY
-
163083362 CRANKSHAFT #1 (MAG)CRANKSHAFT #1 (MAG)
-
163085206 CRANKSHAFT ASSY. (INCL. 5-8, 10-14, 16, 17, 20)CRANKSHAFT ASSY. (INCL. 5-8, 10-14, 16, 17, 20)
-
173084586 BEARING, BALLBEARING, BALL
-
183083094 WASHER, SPRINGWASHER, SPRING
-
193083093 NUTNUT
-
203083713 CRANKSHAFT 2 (CENTER) (INCL. 6, 10)CRANKSHAFT 2 (CENTER) (INCL. 6, 10)
-
213083782 GEAR, DRIVE OIL PUMPGEAR, DRIVE OIL PUMP
