CRANKCASE ASSEMBLY для Polaris 600 XC DELUXE (S00SD6DS) - 2000 года выпуска
-
№АртикулНазвание
-
17516821 SCREWSCREW
-
25131319 PLATE, STOP, TORQUEPLATE, STOP, TORQUE
-
35131677 STUD, CYLINDER FLANGE (152MM)STUD, CYLINDER FLANGE (152MM)
-
47051020 VALVE, CHECK (90 DEG.)VALVE, CHECK (90 DEG.)
-
52201359 CRANKCASE ASSY TWN SNOCTRGD (INCL. 3, 5, 14, 15, 18)CRANKCASE ASSY TWN SNOCTRGD (INCL. 3, 5, 14, 15, 18)
-
65411125 O-RINGO-RING
-
75630610 MANIFOLD, WATER INLETMANIFOLD, WATER INLET
-
85243431 RETAINER, INLET WATER MANIFOLDRETAINER, INLET WATER MANIFOLD
-
97516736 SCREWSCREW
-
108450068-04 HOSEHOSE
-
117080560 CLAMP, S.S.CLAMP, S.S.
-
125411394 SEAL, FLANGEDSEAL, FLANGED
-
137051529 PLUGPLUG
-
147516919 SCREWSCREW
-
157516732 SCREWSCREW
-
167710441 RING, RETAININGRING, RETAINING
-
177052145 FITTINGFITTING
-
187663001 PIN, DOWELPIN, DOWEL
-
198450061-600 FUELLINE (3MMX7MM)FUELLINE (3MMX7MM)
-
207080603 CLAMPCLAMP
-
217555998 WASHER, FLATWASHER, FLAT
-
227052160 VALVE, CHECK, OIL PUMPVALVE, CHECK, OIL PUMP
-
237517319 SCREWSCREW
