STEERING ASSEMBLY для Polaris 600 XC DELUXE (S00SD6DS) - 2000 года выпуска
-
№АртикулНазвание
-
17547029 NUT, FLEX LOCKNUT, FLEX LOCK
-
27555721 WASHERWASHER
-
37558702 WASHER THRUSTWASHER THRUST
-
43514320 BEARING, BALL, 600ILLUBEARING, BALL, 600ILLU
-
51820577 ARM ASSY, IDLER (INCL. 4, 6)ARM ASSY, IDLER (INCL. 4, 6)
-
65010417 BUSHINGBUSHING
-
77542403 NUT LOCKNUT LOCK
-
81820575 ARM ASSY, PITMAN (INCL. 4, 6)ARM ASSY, PITMAN (INCL. 4, 6)
-
97542424 NUTNUT
-
107060164 ROD END (LEFT)ROD END (LEFT)
-
117512404 BOLTBOLT
-
125333411 ROD, DRAGLINKROD, DRAGLINK
-
137542401 NUT HEXNUT HEX
-
147060174 ROD, END, HI-ANGLE (RIGHT) (3/8)ROD, END, HI-ANGLE (RIGHT) (3/8)
-
157542411 NUT LOCKNUT LOCK
-
167060166 ROD END (LEFT)ROD END (LEFT)
-
175020970-067 ROD, TIE (BLK)ROD, TIE (BLK)
-
187517428 BOLTBOLT
-
197661638 RIVET, INTERLOCK BRIVET, INTERLOCK B
-
205241997 BRACKET BOLT RETAINERBRACKET BOLT RETAINER
-
217080561 FITTING, LUB/VENFITTING, LUB/VEN
-
227542303 NUT FLEX, LOCNUT FLEX, LOC
-
237080804 CABLE TIE, RELEASABLE (5 1/2'')CABLE TIE, RELEASABLE (5 1/2'')
-
241013152-067 STEERING, HOOP, WELDSTEERING, HOOP, WELD
-
257512275 BOLT, CARRIAGEBOLT, CARRIAGE
-
267542103 NUT, LOCKNUT, LOCK
-
277661643 RIVET (-3/16-.214-.420)RIVET (-3/16-.214-.420)
-
281012618 STOP, TORQUESTOP, TORQUE
-
297542404 NUTNUT
-
303110078 STOP, TORQUESTOP, TORQUE
-
315411249 BOOT, TIEROD, MODBOOT, TIEROD, MOD
-
325211796-067 PLATE, BOOT, MODPLATE, BOOT, MOD
-
337621323 POP RIVETPOP RIVET
-
347080689 PLUG, HOLEPLUG, HOLE
-
357517402 SCREWSCREW
-
364020139 CLIP, PLASTICCLIP, PLASTIC
-
377515434 SCREWSCREW
-
387515415 BOLTBOLT
-
397555893 WASHERWASHER
-
405411220 O-RINGO-RING
-
415010384 TUBE, SPACERTUBE, SPACER
-
421822479 RACK ASSY, CRCRACK ASSY, CRC
