SEAT W/ GAS TANK ASSEMBLY для Polaris 600 XC DELUXE (S00SD6DS) - 2000 года выпуска
-
№АртикулНазвание
-
12511195-070 CAP ASSY, FUEL (BLK)CAP ASSY, FUEL (BLK)
-
22682567 SEATCOVER, ASSYSEATCOVER, ASSY
-
22682568 SEAT, CUSHION, GEN II (STANDARD) (INCL. 2, 12, 16)SEAT, CUSHION, GEN II (STANDARD) (INCL. 2, 12, 16)
-
37080550 GROMMET, RELATCH (1'') (BOTTOM)GROMMET, RELATCH (1'') (BOTTOM)
-
47080549 GROMMET, RELATCH (1'') (TOP)GROMMET, RELATCH (1'') (TOP)
-
57080548 TWISTLOCK, RELATCH, W/HOLE (1'')TWISTLOCK, RELATCH, W/HOLE (1'')
-
67621337 RIVETRIVET
-
74030024 BULB, TAILLIGHTBULB, TAILLIGHT
-
84030045 BULB, BRAKELIGHTBULB, BRAKELIGHT
-
95430423 LENS, TAILLIGHTLENS, TAILLIGHT
-
107511840 SCREWSCREW
-
115433341 HOUSING, TAILLIGHTHOUSING, TAILLIGHT
-
125243185 RETAINER, CLIP, TOOL POUCHRETAINER, CLIP, TOOL POUCH
-
137621472 RIVETRIVET
-
147558301 WASHERWASHER
-
157512240 BOLTBOLT
-
162460399 HARNESS, TAILLIGHTHARNESS, TAILLIGHT
-
162460686 JUMPER, SEAT, TAIL LIGHTJUMPER, SEAT, TAIL LIGHT
-
177542122 NUT, LOCKNUT, LOCK
-
187555960 WASHERWASHER
-
197670021 SPEED NUTSPEED NUT
-
207512193 BOLTBOLT
-
215810063 PAD, GAS TANKPAD, GAS TANK
-
228350018-600 TUBING, ETHER ERETHANE (160CM)TUBING, ETHER ERETHANE (160CM)
-
237080307 CLAMPCLAMP
-
247052259 FITTING (1/4'' 90Ш DEX)FITTING (1/4'' 90Ш DEX)
-
257052028 GROMMET, TANK FITTINGGROMMET, TANK FITTING
-
267080402 RING, COMPRESSIONRING, COMPRESSION
-
278350019-600 FUEL LINE, ESTERFUEL LINE, ESTER
-
287052243 FUEL PICKUP, W/FILTERFUEL PICKUP, W/FILTER
-
292520176 TANK, FUEL, 12 GAL, W/SENDER, ASSY. (INCL. 24, 32)TANK, FUEL, 12 GAL, W/SENDER, ASSY. (INCL. 24, 32)
-
302410165 SENDER, FUEL, 12.0 GAL, SNOWSENDER, FUEL, 12.0 GAL, SNOW
-
312410232 HARDWARE, PKG, SENDER (INCL. GASKET AND SCREWS)HARDWARE, PKG, SENDER (INCL. GASKET AND SCREWS)
-
327052095 FITTING (90 DEG, 1/8)FITTING (90 DEG, 1/8)
-
338450061-600 FUELLINE (3MMX7MM)FUELLINE (3MMX7MM)
