STEERING ASSEMBLY для Polaris 500 XC (S01NP5AS) - 2001 года выпуска
-
№АртикулНазвание
-
17061057 ROD, END 3/8 (PL, 75Ш, 1.00) (RIGHT)ROD, END 3/8 (PL, 75Ш, 1.00) (RIGHT)
-
27542401 NUT HEXAGONNUT HEXAGON
-
35333949-067 ROD TIE (BLK)ROD TIE (BLK)
-
47542424 NUTNUT
-
57061055 ROD, END 3/8, PL, 75Ш STUD (LEFT)ROD, END 3/8, PL, 75Ш STUD (LEFT)
-
67060176 ROD ENDROD END
-
75333772 STEERING ROD RACK, 11.50STEERING ROD RACK, 11.50
-
85333773-067 ROD DRAGLINK, 12.50, STEEL (BLK)ROD DRAGLINK, 12.50, STEEL (BLK)
-
97542439 NUT, NYLOKNUT, NYLOK
-
107061075 ROD END 3/8 HI ANGLE, PR (LEFT)ROD END 3/8 HI ANGLE, PR (LEFT)
-
115132106 BUSHING REDUCER, 12MM TO .385BUSHING REDUCER, 12MM TO .385
-
121820957 PITMAN ARM, EDGE (INCL. 11, 13, 15)PITMAN ARM, EDGE (INCL. 11, 13, 15)
-
135132495 SPACER TUBE, PITMAN/IDLER ARMSSPACER TUBE, PITMAN/IDLER ARMS
-
147512435 BOLTBOLT
-
153514320 BEARING BALL, 600ILLUBEARING BALL, 600ILLU
-
161820959 IDLER ARM ASSY., EDGE (INCL. 11, 13, 15)IDLER ARM ASSY., EDGE (INCL. 11, 13, 15)
