RAIL ASSEMBLY W/ IDLER WHEELS для Polaris WIDETRACK LX (S04SU4BS) - 2004 года выпуска
-
№АртикулНазвание
-
15430723 INSERTS, WHEELINSERTS, WHEEL
-
23514303 BEARING (1 PER WHEEL)BEARING (1 PER WHEEL)
-
37718407 RING RETAINING (1 PER WHEEL)RING RETAINING (1 PER WHEEL)
-
45333019-067 SPACER (OUTER)SPACER (OUTER)
-
57555726 WASHERWASHER
-
61543021 WHEEL, CARRIER (INCL. 1-3)WHEEL, CARRIER (INCL. 1-3)
-
75020836 SHAFTSHAFT
-
85333020-067 SPACER, IN CARRIER (BLACK)SPACER, IN CARRIER (BLACK)
-
97517731 BOLTBOLT
-
107552603 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
117517435 SCREWSCREW
-
127555893 WASHER, FLATWASHER, FLAT
-
137556130 WASHERWASHER
-
141594083-244 WHEEL, IDLER SCROLLED SILVER ASSYWHEEL, IDLER SCROLLED SILVER ASSY
-
155432535 SPACER, IDLERSPACER, IDLER
-
167555918 BUSHINGBUSHING
-
171594087 WHEEL, PLAIN ASSY (6.38 O.D.)WHEEL, PLAIN ASSY (6.38 O.D.)
-
185020879 SHAFT, IDLERSHAFT, IDLER
-
195130530 BLOCK IDLER BOLT ADJUSTERBLOCK IDLER BOLT ADJUSTER
-
207621501 RIVETRIVET
-
217512225 SCREWSCREW
-
221541133 RAIL SWINGARM, RIVETED ASSY (INCL. 19, 20)RAIL SWINGARM, RIVETED ASSY (INCL. 19, 20)
-
225521452 SLIDER, WHISLIDER, WHI
-
235330171-067 TUBESPACER, CENTER OUTSIDETUBESPACER, CENTER OUTSIDE
-
247556301 BUSHINGBUSHING
-
251590276-244 WHEEL IDLER SCROLL ASSY (SILVER)WHEEL IDLER SCROLL ASSY (SILVER)
-
267621508 RIVETRIVET
-
277517247 SCREWSCREW
-
287555806 WASHER, FLATWASHER, FLAT
-
295630399 SPACERSPACER
-
307542439 NUT, NYLOKNUT, NYLOK
-
317555852 WASHER, FLATWASHER, FLAT
-
321590356-244 WHEEL, 5.62 SCROLL WITH IN ASSY (SILVER)WHEEL, 5.62 SCROLL WITH IN ASSY (SILVER)
-
335333116 SPACER, WHEELSPACER, WHEEL
-
347553101 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
357512538 BOLTBOLT
-
365431531 INSERT, WHEEL (2 PER WHEEL)INSERT, WHEEL (2 PER WHEEL)
-
377710444 RING, RETAININGRING, RETAINING
-
383514012 BEARINGBEARING
-
397512404 BOLTBOLT
-
405431366 ROLLER, SPRINGROLLER, SPRING
-
417621476 RIVETRIVET
-
425222629 REINFORCEMENT, BUMPERREINFORCEMENT, BUMPER
-
435411682 TRACK, SHOCKWAVE (20"X156X1")TRACK, SHOCKWAVE (20"X156X1")
-
435241473 CLIP, SLIDECLIP, SLIDE
-
447512227 SCREWSCREW
-
451540751 RAIL ASSY (LEFT) (INCL. 42, 46, 53)RAIL ASSY (LEFT) (INCL. 42, 46, 53)
-
455521452 SLIDER, WHISLIDER, WHI
-
465430627 COVER RAIL TIPCOVER RAIL TIP
-
477621435 RIVETRIVET
-
485132239 SHAFT PIVOTSHAFT PIVOT
-
497555823 WASHERWASHER
-
501540752 RAIL ASSY (RIGHT) (INCL. 42, 46, 53)RAIL ASSY (RIGHT) (INCL. 42, 46, 53)
-
505521452 SLIDER, WHISLIDER, WHI
-
515020720 SHAFT, SPANNERSHAFT, SPANNER
-
527542122 NUT NYLOKNUT NYLOK
-
535810554 BUMPER, RAILBUMPER, RAIL
-
545333138 SPACER, SHOCK (REAR)SPACER, SHOCK (REAR)
-
555020651 SHAFT SHOCK (REAR)SHAFT SHOCK (REAR)
-
567512659 BOLTBOLT
-
577553201 WASHER, SPLIT LOCKWASHER, SPLIT LOCK
-
587555804 WASHERWASHER
-
595332786 SPACERSPACER
-
601590357 WHEEL, 5.62 PLAIN WITH INSERT ASSY (INCL. 2, 3, 36)WHEEL, 5.62 PLAIN WITH INSERT ASSY (INCL. 2, 3, 36)
-
615130570 BRACKET, BOGIE WHEELBRACKET, BOGIE WHEEL
-
627041231-067 SPRING, EXTENSION (REAR/BLACK)SPRING, EXTENSION (REAR/BLACK)
-
635020726 SHAFT, IDLERSHAFT, IDLER
-
645333014-067 TUBE, CENTER IDLER (BLACK)TUBE, CENTER IDLER (BLACK)
-
655020725 SHAFT, PIVOT ARMSHAFT, PIVOT ARM
-
667515459 SCREWSCREW
-
677542404 NUTNUT
-
685333523 SPACER, IDLERSPACER, IDLER
