THROTTLE BODY W/ INTAKE MANIFOLD для Polaris 700 TURBO SWITCHBACK (S09PR7FS) - 2009 года выпуска
-
№АртикулНазвание
-
13131591 SENSOR-THROTTLE POSITIONSENSOR-THROTTLE POSITION
-
21253519 ASM-THROTTLE BODY 39MMASM-THROTTLE BODY 39MM
-
37080909 CLAMP, NARROW BAND (1.77/2.75)CLAMP, NARROW BAND (1.77/2.75)
-
45413242 ADAPTER-THROTTLE BODY 39MM BOREADAPTER-THROTTLE BODY 39MM BORE
-
50451543 BOLTBOLT
-
60454185 INTAKE GASKET (W/SENSOR HOLE)INTAKE GASKET (W/SENSOR HOLE)
-
61454186 INTAKE GASKET (W/O SENSOR HOLE)INTAKE GASKET (W/O SENSOR HOLE)
-
70451352 SENSOR-T-MAPSENSOR-T-MAP
-
80452958 SCREW-NIPPLESCREW-NIPPLE
-
90452952 O-RINGO-RING
