THROTTLE для Polaris RANGER 500 [A99RF50AA] - 1999 года выпуска
-
№АртикулНазвание
-
17080711 CABLE, THROTTLECABLE, THROTTLE
-
27042032 SPRING, LATCH, RETURNSPRING, LATCH, RETURN
-
37542122 NUT-NYLOKNUT-NYLOK
-
41040720-067 LINK, THROTTLE, BLACKLINK, THROTTLE, BLACK
-
55242725-067 PEDAL, THROTTLE, BLACKPEDAL, THROTTLE, BLACK
-
67555954 WASHERWASHER
-
77661103 PIN, COTTERPIN, COTTER
-
85432940 BLOCK-PIVOT, THROTTLEBLOCK-PIVOT, THROTTLE
-
97515102 SCREWSCREW
-
107546901 NUT, RIGHT HAND, 10 MM.NUT, RIGHT HAND, 10 MM.
-
111012782-067 BRKT, THROTTLEBRKT, THROTTLE
-
127661638 RIVET, INTERLOCK, BRIVET, INTERLOCK, B
Все узлы модели:
- AIR BOX ASSY.
- BRAKE - FRONT
- BRAKE - MIDDLE AND PARKING BRAKE
- BRAKE - REAR
- BRAKE - REAR W/ FOOT PEDAL
- BRAKE LINES
- CAB - FRAME
- CAMSHAFT W/ VALVE ASSY.
- CARBURETOR
- CLUTCH - DRIVE
- CLUTCH - DRIVEN
- CLUTCH COVER
- CONSOLE
- COOLING SYSTEM
- CRANKCASE
- CRANKSHAFT W/ PISTON
- CYLINDER
- DECALS
- DIFFERENTIAL - FRONT (AFTER 1/01/99)
- DIFFERENTIAL - FRONT (BEFORE 11/09/98)
- DIFFERENTIAL - FRONT (BUILT BEFORE 7/01/99 AND AFTER 11/09/98)
- DRIVESHAFT - FRONT
- DRIVESHAFT - INTERMEDIATE
- ELECTRICAL - BATTERY
- EXHAUST SYSTEM
- FRAME - FOOTWELLS
- FRONT GEARCASE INTERNAL COMPONENTS
- FRONT WHEELS
- FUEL TANK
- GEAR SELECTOR
- GEARCASE - CASE AND SNORKLE
- GEARCASE - REAR
- HOOD
- INSTRUMENT PANEL
- MAGNETO
- MID ANGLE DRIVE
- MID AXLE DRIVE SHAFT - LEFT
- MID AXLE DRIVE SHAFT - RIGHT
- MIDDLE WHEEL DRIVE
- MOLDING AND SEAT
- MOUNTING - ENGINE
- OIL FILTER
- OIL PUMP
- OIL TANK
- REAR BOX AND SHOCK MOUNTING
- REAR WHEELS
- STARTER - RECOIL
- STARTING MOTOR
- STEERING POST
- SUSPENSION - FRONT A - ARM W/ TIE RODS
- SUSPENSION - FRONT STRUT
- SUSPENSION - MIDDLE SHOCK MOUNTING
- SUSPENSION - SWING ARM AND REAR SHOCK
- TAIL DRIVE SHAFT
- • THROTTLE
- TOOL KIT
- TRANSMISSION W/ ENGINE MOUNTING
- WATER PUMP
