HEADLIGHT для Yamaha FJR1300A (3P6A) [FJR13AW] - 2007 года выпуска
-
№АртикулНазвание
-
13P6-8430B-20-00 HEADLIGHT SUB ASSYHEADLIGHT SUB ASSY
-
22F9-84314-00-00 ...BULB (12V-60/55W)...BULB (12V-60/55W)
-
35JW-84397-00-00 ...COVER, SOCKET...COVER, SOCKET
-
43P6-8430N-00-00 ...WIRE ASSY...WIRE ASSY
-
53P6-8431U-00-00 HOLDERHOLDER
-
63P6-8431N-00-00 RODROD
-
793440-06190-00 CIRCLIPCIRCLIP
-
890170-10206-00 NUTNUT
-
93P6-8432N-00-00 KNOBKNOB
-
1090157-03007-00 SCREW, PAN HEADSCREW, PAN HEAD
-
113P6-84359-10-00 CORD, HEADLIGHTCORD, HEADLIGHT
-
1290464-12036-00 CLAMPCLAMP
-
1390465-13152-00 CLAMPCLAMP
-
144XV-83513-00-00 DAMPERDAMPER
-
1590160-05006-00 SCREW, ROUND TAPPINGSCREW, ROUND TAPPING
-
1697707-50016-00 SCREW, TRUSS HEAD TAPPINGSCREW, TRUSS HEAD TAPPING
-
1790154-05005-00 SCREW, BINDINGSCREW, BINDING
-
1890183-05076-00 NUT, SPRINGNUT, SPRING
