CONTROL CABLES для Yamaha GP 760 - 2000 года выпуска
-
№АртикулНазвание
-
1GP7-U157A-00-00 GRIP HANDLE ASSY. (YMUS)GRIP HANDLE ASSY. (YMUS)
-
2GP7-U155C-00-00 ...GRIP, HANDLE (YMUS)...GRIP, HANDLE (YMUS)
-
3GP7-U152P-00-00 SPRING (YMUS)SPRING (YMUS)
-
4GP7-U152R-00-00 BALL (YMUS)BALL (YMUS)
-
5GP7-U151M-00-00 LEVER ASSY (YMUS)LEVER ASSY (YMUS)
-
6GP7-U152M-00-00 HOUSING ASSY (YMUS)HOUSING ASSY (YMUS)
-
792990-04600-00 WASHER, PLATEWASHER, PLATE
-
898980-04010-00 SCREW, BINDSCREW, BIND
-
997880-06065-00 SCREW, PAN HEADSCREW, PAN HEAD
-
1092990-06600-00 WASHER, PLATEWASHER, PLATE
-
1192990-06100-00 WASHER, SPRINGWASHER, SPRING
-
12GH1-U143B-00-00 NUT, SPECIAL (YMUS)NUT, SPECIAL (YMUS)
-
13GP7-U153D-00-00 CABLE, NOZZLE CONTROL 2 (YMUS)CABLE, NOZZLE CONTROL 2 (YMUS)
-
1490387-05800-00 COLLAR (YMUS)COLLAR (YMUS)
-
1590110-05908-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
16GP7-U155F-00-00 GRIP, END (YMUS)GRIP, END (YMUS)
-
17GP7-U153E-00-00 CABLE, NOZZLE CONTROL 3 (YMUS)CABLE, NOZZLE CONTROL 3 (YMUS)
-
18GH1-U046C-00-00 ...END, CABLE (YMUS)...END, CABLE (YMUS)
-
19EU0-U1461-30-00 ...JOINT, BALL (YMUS)...JOINT, BALL (YMUS)
-
20EU0-67267-10-00 ...CONNECTOR, CABLE...CONNECTOR, CABLE
-
21EU0-62241-30-00 NUT, DRAIN 1NUT, DRAIN 1
-
22GP7-U153J-00-00 REMOCON, NOZZLE 2 (YMUS)REMOCON, NOZZLE 2 (YMUS)
-
23GP7-U153N-00-00 ...WHEEL (YMUS)...WHEEL (YMUS)
-
24GP7-U153R-00-00 ...ARM ASSY. (YMUS)...ARM ASSY. (YMUS)
-
2595720-05300-00 ...NUT, FLANGE...NUT, FLANGE
-
2692990-05300-00 . WASHER, INTERNAL TOOTH. WASHER, INTERNAL TOOTH
-
2797880-05020-00 ...SCREW, PAN HEAD...SCREW, PAN HEAD
-
28GP7-U153P-00-00 ...WASHER (YMUS)...WASHER (YMUS)
-
2990119-069UJ-00 BOLT, WITH WASHER (YMUS)BOLT, WITH WASHER (YMUS)
-
309708R-06012-00 BOLTBOLT
-
31GH1-U043H-00-00 CLAMP, CABLE (YMUS)CLAMP, CABLE (YMUS)
-
329299R-06200-00 WASHER (YMUS)WASHER (YMUS)
-
339578R-06300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
34GP7-U1481-00-00 CABLE, STEERING (YMUS)CABLE, STEERING (YMUS)
-
35GK5-67267-10-00 ...CONNECTOR, CABLE...CONNECTOR, CABLE
-
36GP8-U1461-T0-00 ...STUD, JOINT BALL (YMUS)...STUD, JOINT BALL (YMUS)
-
37EU0-62241-30-00 NUT, DRAIN 1NUT, DRAIN 1
-
38GK5-U146F-00-00 SHAFT, JOINT BALL (YMUS)SHAFT, JOINT BALL (YMUS)
-
39EU0-U1461-01-00 STOOD, JOINT BALL (YMUS)STOOD, JOINT BALL (YMUS)
-
4090201-06906-00 WASHER, PLATEWASHER, PLATE
-
4195380-06700-00 NUTNUT
-
429572R-06300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
4390699-38U03-00 SPI-WRAP 25 (YMUS)SPI-WRAP 25 (YMUS)
-
4490601-200U1-00 CLAMP, CABLE (TIEWRAP 6") (YMUS)CLAMP, CABLE (TIEWRAP 6") (YMUS)
-
45GP7-U7252-00-00 CABLE, THROTTLE (YMUS)CABLE, THROTTLE (YMUS)
-
4690600-918U3-00 CLIP, NYLON 18 (YMUS)CLIP, NYLON 18 (YMUS)
-
479778R-60116-00 SCREW, TAPPING (YMUS)SCREW, TAPPING (YMUS)
-
48GP7-U7242-01-00 CABLE, CHOKE (YMUS)CABLE, CHOKE (YMUS)
-
49GP7-U724C-00-00 ...KNOB, CHOKE (YMUS)...KNOB, CHOKE (YMUS)
-
50GP7-U724D-00-00 ...SCREW, KNOB (YMUS)...SCREW, KNOB (YMUS)
-
51GP7-U724E-00-00 ...NUT, COMPRESSION (YMUS)...NUT, COMPRESSION (YMUS)
-
52GA9-U724F-01-00 ...NUT, KNURLED (YMUS)...NUT, KNURLED (YMUS)
-
53GJ1-6824D-01-00 PLATE, CHOKEPLATE, CHOKE
