HULL - GUNWALE - MAT для Yamaha XL 700 - 2000 года выпуска
-
№АртикулНазвание
-
1GJ3-U2501-20-00 BOW GUNWALE COMP. (YMUS)BOW GUNWALE COMP. (YMUS)
-
2GU2-6252E-10-00 JOINT, GUNWALE LHJOINT, GUNWALE LH
-
3GU2-6252F-10-00 JOINT, GUNWALE RHJOINT, GUNWALE RH
-
49572R-06300-00 NUT, FLANGE (YMUS)NUT, FLANGE (YMUS)
-
59299R-06200-00 WASHER (YMUS)WASHER (YMUS)
-
6GH3-U2512-20-00 GUNWALE, SIDE (YMUS)GUNWALE, SIDE (YMUS)
-
7GJ3-U2519-40-00 INNER, GUNWALE (YMUS)INNER, GUNWALE (YMUS)
-
890169-059U1-00 SCREW,TAPPING (YMUS)SCREW,TAPPING (YMUS)
-
9GJ3-U251D-21-00 GUNWALE, STERN 1 (YMUS)GUNWALE, STERN 1 (YMUS)
-
10GJ3-U251E-21-00 GUNWALE, STERN 2 (YMUS)GUNWALE, STERN 2 (YMUS)
-
1190267-489U8-00 RIVET, BLIND (YMUS)RIVET, BLIND (YMUS)
-
12GJ3-U354D-30-00 CAP, HEAD (YMUS)CAP, HEAD (YMUS)
-
13GJ3-U252C-20-00 COVER, GUNWALE 1 (YMUS)COVER, GUNWALE 1 (YMUS)
-
14GJ3-U252D-40-00 COVER, GUNWALE 2 (YMUS)COVER, GUNWALE 2 (YMUS)
-
1590267-489U8-00 RIVET, BLIND (YMUS)RIVET, BLIND (YMUS)
-
16FN8-61651-00-00 ROPE HOLEROPE HOLE
-
17EU0-61652-00-00 NUTNUT
-
18GU2-U358F-01-00 MAT, UPPER LH (YMUS)MAT, UPPER LH (YMUS)
-
19GU2-U358G-01-00 MAT, UPPER RH (YMUS)MAT, UPPER RH (YMUS)
-
20GU2-U351H-01-00 MAT, STEP 1 (YMUS)MAT, STEP 1 (YMUS)
-
21GU2-U351J-01-00 MAT, STEP 2 (YMUS)MAT, STEP 2 (YMUS)
-
22GU2-U351N-01-00 MAT, STEP 5 (YMUS)MAT, STEP 5 (YMUS)
-
23GU2-U351P-01-00 MAT, STEP 6 (YMUS)MAT, STEP 6 (YMUS)
-
24GU2-U351R-01-00 MAT, STEP 7 (YMUS)MAT, STEP 7 (YMUS)
-
25GU2-U351S-01-00 MAT, STEP 8 (YMUS)MAT, STEP 8 (YMUS)
-
26GH3-U351M-50-00 MAT, STEP 4 (YMUS)MAT, STEP 4 (YMUS)
-
27GH3-U351M-60-00 MAT, STEP 4 (YMUS)MAT, STEP 4 (YMUS)
-
2890267-48802-00 RIVET, BLIND (YMUS)RIVET, BLIND (YMUS)
-
29GJ3-U352E-50-00 MAT, BOW (YMUS)MAT, BOW (YMUS)
