VENTILATION для Yamaha SV 1200A - 2002 года выпуска
-
№АртикулНазвание
-
1F0D-62127-00-00 BASE, AIR INTAKEBASE, AIR INTAKE
-
2GU5-U213F-00-00 HOSE, VENTILATOR 1HOSE, VENTILATOR 1
-
390267-489UE-00 RIVET, BLINDRIVET, BLIND
-
4F0D-62139-00-00 VENTILATOR, OUTLETVENTILATOR, OUTLET
-
5GU5-U213G-00-00 HOSE, VENTILATOR 2HOSE, VENTILATOR 2
-
690267-489UE-00 RIVET, BLINDRIVET, BLIND
-
790601-200U8-00 BANDBAND
-
89778R-50116-00 SCREW, TAPPINGSCREW, TAPPING
-
9GP7-62159-01-00 SOCKET, VENTILATIONSOCKET, VENTILATION
-
1090267-489UE-00 RIVET, BLINDRIVET, BLIND
-
11GK5-62149-00-00 PIPE, VENTILATIONPIPE, VENTILATION
-
1290601-200U7-00 BANDBAND
-
13GJ3-6215F-00-00 NIPPLENIPPLE
-
1490465-11829-00 CLAMPCLAMP
