CONSOLE ASSY для Yamaha SR VENTURE DX - 2018 года выпуска
-
№АртикулНазвание
-
18JP-K7712-00-00 PANEL, INSTRUMENTPANEL, INSTRUMENT
-
28KC-RA202-00-00 SCREW, TAPPING 1/4-20X0.5SCREW, TAPPING 1/4-20X0.5
-
38JP-K7131-00-00 LOUVER 1LOUVER 1
-
48JP-RA253-00-00 SCREW, M6-1.0X18SCREW, M6-1.0X18
-
58JP-RA373-00-00 NUT, INSERTNUT, INSERT
-
68MU-F835P-00-00 PLATE, WINDSHIELD 2PLATE, WINDSHIELD 2
-
78MU-F8306-00-00 PLATE, WINDSHIELDPLATE, WINDSHIELD
-
88JP-RA363-00-00 NUT, FLANGE LOCKING M5X0.8NUT, FLANGE LOCKING M5X0.8
-
98JP-RA280-00-00 SCREW, TAPPING M6X12SCREW, TAPPING M6X12
-
108LJ-RA239-00-00 SCREW, 5SCREW, 5
-
118JY-K7711-20-00 PANEL, INSTRUMENTPANEL, INSTRUMENT
-
128JP-RA252-00-00 SCREW, M6-1.0X15SCREW, M6-1.0X15
-
138LJ-K6169-00-00 NUTNUT
-
148LJ-K7563-00-00 COVER, 3COVER, 3
-
158LJ-H3619-00-00 PLUG, HEATERPLUG, HEATER
-
168JP-H2627-00-00 SWITCHSWITCH
-
178JP-K6169-00-00 NUTNUT
-
188JP-RA352-00-00 NUT, CLIP 10NUT, CLIP 10
-
198MU-K7713-00-00 PANEL, INSTRUMENTPANEL, INSTRUMENT
-
208MU-K7761-70-00 ...LABEL, WARNING 1...LABEL, WARNING 1
-
218MU-K7761-S0-00 ...LABEL, WARNING 1...LABEL, WARNING 1
-
228JP-K7561-01-00 ...PROTECTOR, SIDE 1...PROTECTOR, SIDE 1
-
238JP-R4261-00-00 ...VELCRO (6.5 FEET)...VELCRO (6.5 FEET)
-
248JP-RA345-00-00 NUT, 1NUT, 1
-
258JP-RAK02-00-00 PIN, 2PIN, 2
