REAR AND PARKING BRAKE ASSEMBLY для Arctic Cat PROWLER XTX (SILVER) [U2008P2T4EUSL] - 2008 года выпуска
-
№АртикулНазвание
-
11402-324 ROTORROTOR
-
20423-557 SCREW, SHOULDERSCREW, SHOULDER
-
31502-143 BRAKE - ASSEMBLY (INC. 4-13)BRAKE - ASSEMBLY (INC. 4-13)
-
40502-988 ...NUT...NUT
-
51502-160 ...KIT-ACTUATION LEVER W/SPRING HOLE...KIT-ACTUATION LEVER W/SPRING HOLE
-
60502-985 ...SPRING...SPRING
-
80502-609 ...VALVE, BLEED...VALVE, BLEED
-
100502-605 ...BRACKET ASSEMBLY...BRACKET ASSEMBLY
-
121436-165 ...KIT-PAD, BRAKE-SET (TYPE 97)...KIT-PAD, BRAKE-SET (TYPE 97)
-
131502-161 ...KIT, PAD SPRINGS-ANTI/RATTLE...KIT, PAD SPRINGS-ANTI/RATTLE
-
140487-036 CABLE, PARKING BRAKECABLE, PARKING BRAKE
-
151502-354 PARKING BRAKE ASSY W/O CABLE (INC. 16-21)PARKING BRAKE ASSY W/O CABLE (INC. 16-21)
-
161502-030 ...PIN, C...PIN, C
-
170423-667 ...E-CLIP...E-CLIP
-
180402-991 ...RETAINER, BRAKE SWITCH...RETAINER, BRAKE SWITCH
-
191502-028 ...PIN, A...PIN, A
-
208050-212 ...WASHER...WASHER
-
211502-027 ...SPRING, B...SPRING, B
-
221502-026 SPRING, ASPRING, A
-
231502-360 SPRING, CSPRING, C
-
240423-668 E-CLIPE-CLIP
-
251502-361 PINPIN
-
260487-058 CABLE, BRAKE RELEASECABLE, BRAKE RELEASE
-
270623-044 WASHERWASHER
-
288424-602 NUTNUT
-
291502-024 HANDLE, PARKING BRAKEHANDLE, PARKING BRAKE
-
308408-816 SCREW, CAPSCREW, CAP
-
318424-802 NUT, HEXNUT, HEX
-
321502-324 PAD, BRAKEPAD, BRAKE
-
338474-516 SCREW,MACH-TSFH M5X0.8X16 CL8.8 BLKSCREW,MACH-TSFH M5X0.8X16 CL8.8 BLK
-
348422-502 NUTNUT
-
350423-178 WASHER, CRUSHWASHER, CRUSH
-
360423-413 BOLT, BANJO-FITTINGBOLT, BANJO-FITTING
-
371402-388 HOSE, BRAKEHOSE, BRAKE
-
388408-836 SCREW, CAPSCREW, CAP
