THROTTLE BODY ASSEMBLY для Arctic Cat PROWLER XTX (SILVER) [U2008P2T4EUSL] - 2008 года выпуска
-
№АртикулНазвание
-
10470-753 THROTTLE BODY - ASSEMBLY (INC. 2-19)THROTTLE BODY - ASSEMBLY (INC. 2-19)
-
30430-072 ...SENSOR, THROTTLE POSITION...SENSOR, THROTTLE POSITION
-
45507-234 ...O-RING, THROTTLE POSITION SENSOR...O-RING, THROTTLE POSITION SENSOR
-
55507-231 ...SCREW, THROTTLE POSITION SENSOR...SCREW, THROTTLE POSITION SENSOR
-
60430-074 ...VALVE, ISC...VALVE, ISC
-
75507-233 ...O-RING, ISC VALVE...O-RING, ISC VALVE
-
85507-238 ...SCREW...SCREW
-
90470-687 ...RAIL, FUEL...RAIL, FUEL
-
100470-767 ...O-RING, FUEL INJECTOR...O-RING, FUEL INJECTOR
-
110470-762 ...INJECTOR, FUEL...INJECTOR, FUEL
-
120470-768 ...SEAL, FUEL INJECTOR...SEAL, FUEL INJECTOR
-
135507-227 ...BRACKET, MAP SENSOR...BRACKET, MAP SENSOR
-
145507-117 ...SCREW...SCREW
-
150430-073 ...SENSOR, MAP...SENSOR, MAP
-
165507-232 ...O-RING, MAP SENSOR...O-RING, MAP SENSOR
-
175507-229 ...PLATE, ISC VALVE...PLATE, ISC VALVE
-
185507-223 ...COVER...COVER
-
195507-037 ...SCREW...SCREW
-
200487-047 CABLE, THROTTLECABLE, THROTTLE
