TRANSMISSION ASSEMBLY для Arctic Cat PROWLER XTX (SILVER) [U2008P2T4EUSL] - 2008 года выпуска
-
№АртикулНазвание
-
10823-254 PULLEY, DRIVEN - ASSEMBLY (INC. 2-4)PULLEY, DRIVEN - ASSEMBLY (INC. 2-4)
-
20823-176 ...SHOE, CAM...SHOE, CAM
-
30823-177 ...SCREW, CAM...SCREW, CAM
-
40823-178 ...NUT, DRIVEN PULLEY...NUT, DRIVEN PULLEY
-
50823-098 CLUTCH, CENTRIFUGAL - 6 PLATECLUTCH, CENTRIFUGAL - 6 PLATE
-
60832-060 BEARINGBEARING
-
70831-078 RING, RETAININGRING, RETAINING
-
80827-010 NUTNUT
-
90828-106 WASHERWASHER
-
100823-008 PLATE, MOVABLE DRIVE FACEPLATE, MOVABLE DRIVE FACE
-
110823-010 DAMPER, MOVABLE DRIVE FACEDAMPER, MOVABLE DRIVE FACE
-
120823-159 FACE, MOVABLE DRIVEFACE, MOVABLE DRIVE
-
130823-013 V-BELTV-BELT
-
140823-149 SPACER, MOVABLE DRIVE FACESPACER, MOVABLE DRIVE FACE
-
150823-164 ROLLER, MOVABLE DRIVE FACEROLLER, MOVABLE DRIVE FACE
-
160823-156 FACE, FIXED DRIVEFACE, FIXED DRIVE
-
170823-131 SHROUD, DRIVE FACESHROUD, DRIVE FACE
-
180623-914 SCREW, SELF-TAPPINGSCREW, SELF-TAPPING
-
190823-015 SPACER, FIXED DRIVE FACESPACER, FIXED DRIVE FACE
-
200470-531 O-RINGO-RING
-
210830-034 SEAL, CLUTCH HOUSING - RIGHTSEAL, CLUTCH HOUSING - RIGHT
-
220823-096 HOUSING, CLUTCHHOUSING, CLUTCH
-
230832-047 BEARINGBEARING
-
240826-029 SCREW, BEARING RETAINERSCREW, BEARING RETAINER
-
250822-010 RETAINER, BEARINGRETAINER, BEARING
-
260828-075 SHIMSHIM
-
270823-017 SEAL, CLUTCH HOUSING - LEFTSEAL, CLUTCH HOUSING - LEFT
-
280827-011 NUTNUT
-
290823-018 CLUTCH, ONE-WAYCLUTCH, ONE-WAY
