ALTERNATE CARBURETOR PARTS для Arctic Cat ZR 2K - 2000 года выпуска
-
№АртикулНазвание
-
286505-270 MAIN JET, 120MAIN JET, 120
-
286505-216 MAIN JET, 130MAIN JET, 130
-
286505-217 MAIN JET, 140MAIN JET, 140
-
286505-168 MAIN JET, 150MAIN JET, 150
-
286505-064 MAIN JET, 160MAIN JET, 160
-
286505-065 MAIN JET, 170MAIN JET, 170
-
286505-056 MAIN JET, 180MAIN JET, 180
-
286505-066 MAIN JET, 190MAIN JET, 190
-
286505-144 MAIN JET, 200MAIN JET, 200
-
286505-145 MAIN JET, 210MAIN JET, 210
-
286505-137 MAIN JET, 220MAIN JET, 220
-
286505-067 MAIN JET, 230MAIN JET, 230
-
286505-079 MAIN JET, 240MAIN JET, 240
-
286505-068 MAIN JET, 250MAIN JET, 250
-
286505-017 MAIN JET, 260MAIN JET, 260
-
286505-069 MAIN JET, 270MAIN JET, 270
-
286505-080 MAIN JET, 280MAIN JET, 280
-
286505-123 MAIN JET, 290MAIN JET, 290
-
286505-128 MAIN JET, 300MAIN JET, 300
-
286505-136 MAIN JET, 310MAIN JET, 310
-
286505-074 MAIN JET, 320MAIN JET, 320
-
286505-070 MAIN JET, 330MAIN JET, 330
-
286505-076 MAIN JET, 340MAIN JET, 340
-
286505-071 MAIN JET, 350MAIN JET, 350
-
286505-038 MAIN JET, 360MAIN JET, 360
-
286505-072 MAIN JET, 370MAIN JET, 370
-
286505-077 MAIN JET, 380MAIN JET, 380
-
286505-078 MAIN JET, 390MAIN JET, 390
-
286505-124 MAIN JET, 400MAIN JET, 400
-
286505-212 MAIN JET, 410MAIN JET, 410
-
286505-125 MAIN JET, 420MAIN JET, 420
-
286505-146 MAIN JET, 430MAIN JET, 430
-
286505-126 MAIN JET, 440MAIN JET, 440
-
286505-147 MAIN JET, 450MAIN JET, 450
-
286505-127 MAIN JET, 460MAIN JET, 460
-
286505-148 MAIN JET, 470MAIN JET, 470
-
286505-149 MAIN JET, 480MAIN JET, 480
-
286505-150 MAIN JET, 490MAIN JET, 490
-
286505-151 MAIN JET, 500MAIN JET, 500
-
286505-530 MAIN JET, 520MAIN JET, 520
-
286505-170 MAIN JET, 530MAIN JET, 530
-
286505-531 MAIN JET, 540MAIN JET, 540
-
286505-172 MAIN JET, 560MAIN JET, 560
-
286505-211 MAIN JET, 580MAIN JET, 580
-
286505-173 MAIN JET, 590MAIN JET, 590
-
286505-532 MAIN JET, 600MAIN JET, 600
-
286505-174 MAIN JET, 620MAIN JET, 620
-
286505-533 MAIN JET, 640MAIN JET, 640
-
286505-534 MAIN JET, 650MAIN JET, 650
-
286505-535 MAIN JET, 660MAIN JET, 660
-
286505-169 MAIN JET, 680MAIN JET, 680
-
286505-536 MAIN JET, 700MAIN JET, 700
-
286505-537 MAIN JET, 710MAIN JET, 710
-
286505-538 MAIN JET, 720MAIN JET, 720
-
286505-931 NEEDLE JET (VM, STYLE) O, 6 (480)NEEDLE JET (VM, STYLE) O, 6 (480)
-
286505-181 NEEDLE JET (VM, STYLE) O, 8 (182)NEEDLE JET (VM, STYLE) O, 8 (182)
-
286505-824 NEEDLE JET (VM, STYLE) O, 8 (480)NEEDLE JET (VM, STYLE) O, 8 (480)
-
286505-155 NEEDLE JET (VM, STYLE) P, 0 (159)NEEDLE JET (VM, STYLE) P, 0 (159)
-
286505-007 NEEDLE JET (VM, STYLE) P, 0 (166)NEEDLE JET (VM, STYLE) P, 0 (166)
-
286505-051 NEEDLE JET (VM, STYLE) P, 0 (169)NEEDLE JET (VM, STYLE) P, 0 (169)
-
286505-598 NEEDLE JET (VM, STYLE) P, 0 (480)NEEDLE JET (VM, STYLE) P, 0 (480)
-
286505-600 NEEDLE JET (VM, STYLE) P, 2 (480)NEEDLE JET (VM, STYLE) P, 2 (480)
-
286505-221 NEEDLE JET (VM, STYLE) P, 4 (159)NEEDLE JET (VM, STYLE) P, 4 (159)
-
286505-502 NEEDLE JET (VM, STYLE) P, 4 (166)NEEDLE JET (VM, STYLE) P, 4 (166)
-
286505-540 NEEDLE JET (VM, STYLE) P, 4 (480)NEEDLE JET (VM, STYLE) P, 4 (480)
-
286505-164 NEEDLE JET (VM, STYLE) P, 4 (169)NEEDLE JET (VM, STYLE) P, 4 (169)
-
286505-542 NEEDLE JET (VM, STYLE) P, 5 (480)NEEDLE JET (VM, STYLE) P, 5 (480)
-
286505-247 NEEDLE JET (VM, STYLE) P, 6 (159)NEEDLE JET (VM, STYLE) P, 6 (159)
-
286505-268 NEEDLE JET (VM, STYLE) P, 6 (166)NEEDLE JET (VM, STYLE) P, 6 (166)
-
286505-539 NEEDLE JET (VM, STYLE) P, 6 (480)NEEDLE JET (VM, STYLE) P, 6 (480)
-
286505-235 NEEDLE JET (VM, STYLE) P, 6 (251)NEEDLE JET (VM, STYLE) P, 6 (251)
-
286505-298 NEEDLE JET (VM, STYLE) P, 8 (159)NEEDLE JET (VM, STYLE) P, 8 (159)
-
286505-433 NEEDLE JET (VM, STYLE) P, 8 (166)NEEDLE JET (VM, STYLE) P, 8 (166)
-
286505-543 NEEDLE JET (VM, STYLE) P, 8 (480)NEEDLE JET (VM, STYLE) P, 8 (480)
-
286505-260 NEEDLE JET (VM, STYLE) Q, 0 (159)NEEDLE JET (VM, STYLE) Q, 0 (159)
-
286505-190 NEEDLE JET (VM, STYLE) Q, 0 (166)NEEDLE JET (VM, STYLE) Q, 0 (166)
-
286505-529 NEEDLE JET (VM, STYLE) Q, 0 (480)NEEDLE JET (VM, STYLE) Q, 0 (480)
-
286505-508 NEEDLE JET (VM, STYLE) Q, 2 (166)NEEDLE JET (VM, STYLE) Q, 2 (166)
-
286505-641 NEEDLE JET (VM, STYLE) Q, 2 (480)NEEDLE JET (VM, STYLE) Q, 2 (480)
-
286505-599 NEEDLE JET (VM, STYLE) Q, 3 (480)NEEDLE JET (VM, STYLE) Q, 3 (480)
-
286505-214 NEEDLE JET (VM, STYLE) Q, 4 (166)NEEDLE JET (VM, STYLE) Q, 4 (166)
-
286505-636 NEEDLE JET (VM, STYLE) Q, 4 (480)NEEDLE JET (VM, STYLE) Q, 4 (480)
-
286505-119 NEEDLE JET (VM, STYLE) Q, 5 (159)NEEDLE JET (VM, STYLE) Q, 5 (159)
-
286505-520 NEEDLE JET (VM, STYLE) Q, 5 (166)NEEDLE JET (VM, STYLE) Q, 5 (166)
-
286505-580 NEEDLE JET (VM, STYLE) Q, 5 (480)NEEDLE JET (VM, STYLE) Q, 5 (480)
-
286505-506 NEEDLE JET (VM, STYLE) Q, 6 (166)NEEDLE JET (VM, STYLE) Q, 6 (166)
-
286506-112 NEEDLE JET (VM, STYLE) Q, 8 (480)NEEDLE JET (VM, STYLE) Q, 8 (480)
-
286505-505 NEEDLE JET (VM, STYLE) R, 0 (166)NEEDLE JET (VM, STYLE) R, 0 (166)
-
286505-808 NEEDLE JET (VM, STYLE) Z, 4 (224)NEEDLE JET (VM, STYLE) Z, 4 (224)
-
286505-541 NEEDLE JET (VM, STYLE) Z, 5 (224)NEEDLE JET (VM, STYLE) Z, 5 (224)
-
286505-597 NEEDLE JET (VM, STYLE) Z, 6 (224)NEEDLE JET (VM, STYLE) Z, 6 (224)
-
286505-572 NEEDLE JET (VM, STYLE) Z, 8 (224)NEEDLE JET (VM, STYLE) Z, 8 (224)
-
286505-618 NEEDLE JET (VM, STYLE) Z, 9 (224)NEEDLE JET (VM, STYLE) Z, 9 (224)
-
286505-544 NEEDLE JET (VM, STYLE) AA, 0 (224)NEEDLE JET (VM, STYLE) AA, 0 (224)
-
286505-609 NEEDLE JET (VM, STYLE) AA, 1 (224)NEEDLE JET (VM, STYLE) AA, 1 (224)
-
286505-545 NEEDLE JET (VM, STYLE) AA, 2 (224)NEEDLE JET (VM, STYLE) AA, 2 (224)
-
286505-604 NEEDLE JET (VM, STYLE) AA, 3 (224)NEEDLE JET (VM, STYLE) AA, 3 (224)
-
286505-605 NEEDLE JET (VM, STYLE) AA, 4 (224)NEEDLE JET (VM, STYLE) AA, 4 (224)
-
286505-099 NEEDLE JET (VM, STYLE) AA, 5 (224)NEEDLE JET (VM, STYLE) AA, 5 (224)
-
286505-571 NEEDLE JET (VM, STYLE) AA, 8 (224)NEEDLE JET (VM, STYLE) AA, 8 (224)
-
286505-182 NEEDLE JET (VM, STYLE) BB, 0 (224)NEEDLE JET (VM, STYLE) BB, 0 (224)
-
286505-180 NEEDLE JET (VM, STYLE) BB, 5 (224)NEEDLE JET (VM, STYLE) BB, 5 (224)
-
286505-218 PILOT JET, 17.5PILOT JET, 17.5
-
286505-138 PILOT JET, 20PILOT JET, 20
-
286505-310 PILOT JET, 22.5PILOT JET, 22.5
-
286505-075 PILOT JET, 25PILOT JET, 25
-
286505-503 PILOT JET, 27.5PILOT JET, 27.5
-
286505-073 PILOT JET, 30PILOT JET, 30
-
286505-029 PILOT JET, 35PILOT JET, 35
-
286505-047 PILOT JET, 40PILOT JET, 40
-
286505-278 PILOT JET, 45PILOT JET, 45
-
286505-262 PILOT JET, 50PILOT JET, 50
-
286505-261 PILOT JET, 52.5PILOT JET, 52.5
-
286505-255 PILOT JET, 55PILOT JET, 55
-
286505-519 JET NEEDLE, 6CH3JET NEEDLE, 6CH3
-
286505-252 JET NEEDLE, 6DH2JET NEEDLE, 6DH2
-
286505-509 JET NEEDLE, 6DH3JET NEEDLE, 6DH3
-
286505-003 JET NEEDLE, 6DH4JET NEEDLE, 6DH4
-
286505-215 JET NEEDLE, 6DH7JET NEEDLE, 6DH7
-
286505-236 JET NEEDLE, 6DH8JET NEEDLE, 6DH8
-
286505-549 JET NEEDLE, 7DJ2JET NEEDLE, 7DJ2
-
286505-097 JET NEEDLE, 7DH2JET NEEDLE, 7DH2
-
286505-814 JET NEEDLE, 7DH5JET NEEDLE, 7DH5
-
286505-026 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 30, 32, 34INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 30, 32, 34
-
286505-160 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 28, 30, 32, 34INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 28, 30, 32, 34
-
286505-245 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 34 GVMINLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 28, 34 GVM
-
286505-103 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
286505-171 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.5 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
286505-175 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.8 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 1.8 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
286505-176 INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 2.0 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44INLET NEEDLE ASSY. (VM, STYLE) SEAT DIA.: 2.0 MM (VITON) ; CARB. SIZE (MM) : 36, 38, 40, 44
-
286506-121 INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 38INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.5 MM (STEEL) ; CARB. SIZE (MM) : 38
-
286506-144 INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.8 MM (STEEL) ; CARB. SIZE (MM) : 38INLET NEEDLE ASSY. (TM, STYLE) SEAT DIA.: 1.8 MM (STEEL) ; CARB. SIZE (MM) : 38
-
286505-048 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 28, 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 28, 30
-
286505-161 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 28, 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 28, 30
-
286505-510 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 30
-
286505-528 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 30PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 30
-
286505-256 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 1.5; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 1.5; CARBURETOR SIZE (MM) : 32, 34
-
286505-246 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 32, 34
-
286505-439 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 32, 34
-
286505-248 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 32, 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 32, 34
-
286505-500 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34
-
286505-614 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 34
-
286505-507 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34
-
286505-561 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 34
-
286505-877 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 36PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 36
-
286505-592 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 36PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 36
-
286505-254 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 38
-
286505-643 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38
-
286505-436 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
286505-525 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
286505-526 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
286505-554 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
286505-613 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
286505-504 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 4.0; CARBURETOR SIZE (MM) : 38PISTON VALVE ASSY. (VM, STYLE) SLIDE: 4.0; CARBURETOR SIZE (MM) : 38
-
286505-575 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 40PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 40
-
286505-092 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 1.0; CARBURETOR SIZE (MM) : 40, 44PISTON VALVE ASSY. (VM, STYLE) SLIDE: 1.0; CARBURETOR SIZE (MM) : 40, 44
-
286505-179 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 40, 44PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 40, 44
-
286505-570 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 40, 44PISTON VALVE ASSY. (VM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 40, 44
-
286505-548 PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 40, 44PISTON VALVE ASSY. (VM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 40, 44
-
286506-119 THROTTLE VALVE (TM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 38THROTTLE VALVE (TM, STYLE) SLIDE: 2.0; CARBURETOR SIZE (MM) : 38
-
286506-120 THROTTLE VALVE (TM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38THROTTLE VALVE (TM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38
-
286506-232 THROTTLE VALVE (TM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38THROTTLE VALVE (TM, STYLE) SLIDE: 3.0; CARBURETOR SIZE (MM) : 38
-
286506-210 THROTTLE VALVE (TM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38THROTTLE VALVE (TM, STYLE) SLIDE: 3.5; CARBURETOR SIZE (MM) : 38
-
286506-273 THROTTLE VALVE (TM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 40THROTTLE VALVE (TM, STYLE) SLIDE: 2.5; CARBURETOR SIZE (MM) : 40
