07- Off Power Assisted Steering для BRP GTI LE - 2003
-
№АртикулНазвание
-
1277000979 ''U'' Lever''U'' Lever
-
2271000321 Venturi BushingVenturi Bushing
-
3277000980 BushingBushing
-
4234082600 Flat Washer 8 mmFlat Washer 8 mm
-
5250000150 Hex. Screw M8 x 20 (Scotch Grip)Hex. Screw M8 x 20 (Scotch Grip)
-
6277000978 LeverLever
-
7293900042 Flanged BushingFlanged Bushing
-
8207162560 Hex. Screw M6 x 25Hex. Screw M6 x 25
-
9232561600 Elastic Stop Nut M6Elastic Stop Nut M6
-
10277001018 Sealed TubeSealed Tube
-
11277001164 Rod GrommetRod Grommet
-
12296000309 Sealant Silicone, ClearSealant Silicone, Clear
-
13211000023 Hex. Screw #10 x 7/8''Hex. Screw #10 x 7/8''
-
14277001062 Tie Rod R.HTie Rod R.H
-
277001019 Tie Rod L.HTie Rod L.H
-
15277000998 Stabiliser FittingStabiliser Fitting
-
16277001177 Support Plate Ass'ySupport Plate Ass'y
-
17277001177 Support Plate Ass'ySupport Plate Ass'y
-
18241142560 Hex. Flanged Screw K40 x 25Hex. Flanged Screw K40 x 25
-
20277001142 Cylinder Support R.HCylinder Support R.H
-
277001138 Cylinder Support L.HCylinder Support L.H
-
21277000962 SpringSpring
-
22277001091 Pivot RodPivot Rod
-
23277001080 Piston ass'yPiston ass'y
-
24250400014 Spring PinSpring Pin
-
25277001168 SpacerSpacer
-
26277001139 Cover Ass'y. Includes 26 - 29.Cover Ass'y. Includes 26 - 29.
-
27277001140 Threaded CoverThreaded Cover
-
30293250119 SealSeal
-
31277001185 Locking InsertLocking Insert
-
32205562560 Socket Head Screw M6 x 25 (Scotch Grip)Socket Head Screw M6 x 25 (Scotch Grip)
-
33271001298 Elbow Ass'yElbow Ass'y
-
34293800018 Loctite 592, Pipe Sealant, 50 mlLoctite 592, Pipe Sealant, 50 ml
-
35276000101 Formed HoseFormed Hose
-
36293650080 Norma ClampNorma Clamp
-
37277001178 Valve Ass'y. Includes 37 - 42.Valve Ass'y. Includes 37 - 42.
-
38277000990 Valve HousingValve Housing
-
39277001179 PistonPiston
-
40414542700 O-RingO-Ring
-
41277001140 Threaded CoverThreaded Cover
-
42293250144 SealSeal
-
43211000023 Hex. Screw #10 x 7/8''Hex. Screw #10 x 7/8''
-
44276000001 Hose 12.5 mmHose 12.5 mm
-
45293650130 Tridon ClampTridon Clamp
-
46293650123 Oetiker ClampOetiker Clamp
-
47277001144 R.H. Side VaneR.H. Side Vane
-
277001143 LH Side VaneLH Side Vane
-
48205042560 Socket Head Screw M4 x 25Socket Head Screw M4 x 25
-
49250000077 Hex. Screw M8 x 110Hex. Screw M8 x 110
-
50232581600 Elastic Stop Nut M8Elastic Stop Nut M8
