FRAME для Kawasaki Concours - 2005 года выпуска
-
№АртикулНазвание
-
130130G1020 BOLT, FLANGED, 10X20BOLT, FLANGED, 10X20
-
130A130G1030 BOLT, FLANGED, 10X30BOLT, FLANGED, 10X30
-
410410F1800 W, PLAIN, SW, PLAIN, S
-
3200232002-1878 FRAME, COMP, FRONTFRAME, COMP, FRONT
-
32002A32002-1879 FRAME, COMP, AL, REARFRAME, COMP, AL, REAR
-
9201592015-1404 NUT, 18MMNUT, 18MM
-
92015A92015-1546 NUT, 25MM, T=12NUT, 25MM, T=12
-
92015B92015-1796 NUT, CRIMP 6MMNUT, CRIMP 6MM
-
9204992049-1162 SEAL, OIL, XMHE36X52X4JSEAL, OIL, XMHE36X52X4J
-
92049A92049-1214 SEAL, OIL, STEERING STEMSEAL, OIL, STEERING STEM
-
9205592055-1459 O-RING, ID=24.5O-RING, ID=24.5
-
9211692116-1009 BEARING, ROLLER, HR320/28XJBEARING, ROLLER, HR320/28XJ
-
92116A92116-1056 BEARING, ROLLER, HI, CAP32005JR, 1BEARING, ROLLER, HI, CAP32005JR, 1
-
9220092200-1357 WASHER, CLAW, 18.5X30X2.3WASHER, CLAW, 18.5X30X2.3
