ENGINE CASE для Ktm 520 MXC Racing - 2001 года выпуска
-
№АртикулНазвание
-
0159030000044 ENGINE CASE CPL.W.TR.BEAR.ENGINE CASE CPL.W.TR.BEAR.
-
251030026100 DOWEL 17 X14 X12DOWEL 17 X14 X12
-
349030090000 DOWEL 9,8 X 7 X 10DOWEL 9,8 X 7 X 10
-
459030090000 HANGER FOR VENT HOSEHANGER FOR VENT HOSE
-
50014060153 HH COLLAR SCREW MX15 WS=8HH COLLAR SCREW MX15 WS=8
-
658030021000 OILDRAIN PLUG W.MAGNET M12X1,5OILDRAIN PLUG W.MAGNET M12X1,5
-
758038022000 CU-SEAL RING DIN7603-12X18X1,5CU-SEAL RING DIN7603-12X18X1,5
-
90908120153 PLUG DIN0908-M12X1,5PLUG DIN0908-M12X1,5
-
1050130027000 DOWEL 19 X15,1X12DOWEL 19 X15,1X12
-
1158038023300 PRESSURE SPRING L=25MM D=1MMPRESSURE SPRING L=25MM D=1MM
-
1258038028000 VALVE PISTON D=10MMVALVE PISTON D=10MM
-
1759031050000 TUBE ENGINE BREATHER 0,71MTUBE ENGINE BREATHER 0,71M
-
1859030022100 BLEEDER FLANGE M12X1,5 WS=13BLEEDER FLANGE M12X1,5 WS=13
-
1958030080000 LOCATING SCREW M8LOCATING SCREW M8
-
2058030081000 CU-SEAL RING 8 X 14 X 3CU-SEAL RING 8 X 14 X 3
-
2259030019000 OIL LEVEL VIEWER G 1777 YOIL LEVEL VIEWER G 1777 Y
-
2359030020044 OIL DIPSTICK CPL. L=102MMOIL DIPSTICK CPL. L=102MM
-
240770191015 O-RING 19,00X3,00 NBRO-RING 19,00X3,00 NBR
-
260402040980 NEEDLE ROL.DIN5402 NRB 4X 9,8NEEDLE ROL.DIN5402 NRB 4X 9,8
-
300985050083 FLAT HEAD SCREW DIN7985-M 5X 8FLAT HEAD SCREW DIN7985-M 5X 8
-
3259013068000 BRACKET BRAKE FLUID RESERVOIRBRACKET BRAKE FLUID RESERVOIR
-
3359030001090 RET.BRACKET F,BRAKE LEVER HUBRET.BRACKET F,BRAKE LEVER HUB
-
340770120020 O-RING 2X12O-RING 2X12
-
3559038014000 PLUG M16X1,5PLUG M16X1,5
-
3659038015000 OIL SCREEN 11,8X44,5MMOIL SCREEN 11,8X44,5MM
-
370770090015 O-RING 9X1,5 NBRO-RING 9X1,5 NBR
-
380603121830 SEAL RING DIN7603 12X18X3SEAL RING DIN7603 12X18X3
-
3958038022000 CU-SEAL RING DIN7603-12X18X1,5CU-SEAL RING DIN7603-12X18X1,5
-
4159030025000 CLUTCH COVER GASKET 0,5MMCLUTCH COVER GASKET 0,5MM
-
4259030039000 ENGINE CASE GASKETENGINE CASE GASKET
-
4359030001000 CLUTCH COVERCLUTCH COVER
-
4459030047000 CHAIN DAMPERSHEETCHAIN DAMPERSHEET
-
4659030060000 SPROCKET COVERSPROCKET COVER
-
4754613038150 BUSHING,5X8X11BUSHING,5X8X11
-
480015060403 HH COLLAR SCREW MX40 WS=8HH COLLAR SCREW MX40 WS=8
-
490015060203 HH COLLAR SCREW MX20 WS=8HH COLLAR SCREW MX20 WS=8
-
500015060453 HH COLLAR SCREW MX45 WS=8HH COLLAR SCREW MX45 WS=8
-
510015060603 HH COLLAR SCREW MX60 WS=8HH COLLAR SCREW MX60 WS=8
-
520015060303 HH COLLAR SCREW MX30 WS=8HH COLLAR SCREW MX30 WS=8
-
530015060353 HH COLLAR SCREW MX35 WS=8HH COLLAR SCREW MX35 WS=8
-
540015060753 HH COLLAR SCREW MX75 WS=8HH COLLAR SCREW MX75 WS=8
-
5550308053000 BUSH FOR SPOILERX11X16X7,5BUSH FOR SPOILERX11X16X7,5
-
6059030099000 GASKET SET CPL.GASKET SET CPL.
