REAR WHEEL 18'' для Ktm 950 ADVENTURE (S) - 2005 года выпуска
-
№АртикулНазвание
-
16001000114430 REAR WHEEL CPL.4,25X18" BLA.REAR WHEEL CPL.4,25X18" BLA.
-
260010010044 REAR HUB CPL.REAR HUB CPL.
-
360010011000 BEAR. SPACERTUBE L=1248MMBEAR. SPACERTUBE L=1248MM
-
40625062052 GR.BALL BEAR. 6205-2RSHC3HMTF7GR.BALL BEAR. 6205-2RSHC3HMTF7
-
50472052200 CIRCLIP DIN0472-52X2CIRCLIP DIN0472-52X2
-
60760305271 SHAFT SEAL RING 30X52X7SHAFT SEAL RING 30X52X7
-
760010013000 SPACER BUSH. REAR WHEEL R/SSPACER BUSH. REAR WHEEL R/S
-
860010015000 SPACER RINGSPACER RING
-
96001007010030 REAR RIM 4,25X18 BLACKREAR RIM 4,25X18 BLACK
-
1060010171000 SPOKE M5X219 19 DEGSPOKE M5X219 19 DEG
-
1160010071000 SPOKEM5X194 IV DEGSPOKEM5X194 IV DEG
-
1258309072000 SPOKE NIPPLE M5-TA (8X21MM)SPOKE NIPPLE M5-TA (8X21MM)
-
1360010074000 TYRE 150/70-R18 M/C 70V MT90TYRE 150/70-R18 M/C 70V MT90
-
1460010075000 HOSEMD18HOSEMD18
-
1560010073000 RIM TAPE 18" 50/2RIM TAPE 18" 50/2
-
2060010051042 REAR SPROCKET 42-TREAR SPROCKET 42-T
-
2060010051045 REAR SPROCKET 45-TREAR SPROCKET 45-T
-
2160010052000 SPROCKET SCREW M1OX1,25SPROCKET SCREW M1OX1,25
-
220980101253 HEXAG.NUT DIN 980V M10X1,25 SLHEXAG.NUT DIN 980V M10X1,25 SL
-
2360010050044 SPROCKET SUPPORT CPL.SPROCKET SUPPORT CPL.
-
2460010012000 SPACER BUSH. SPROCKET SUPP.SPACER BUSH. SPROCKET SUPP.
-
2560010016000 NILOS RING 7206 AVHNILOS RING 7206 AVH
-
260625032067 BALL BEARING 3206 2RS1BALL BEARING 3206 2RS1
-
2760010014000 SPACER BUSH. SPR. SUPP IN.SPACER BUSH. SPR. SUPP IN.
-
2854610459000 DAMPING RUBBERDAMPING RUBBER
-
2960010060000 REAR BRAKE DISK D=240MMREAR BRAKE DISK D=240MM
-
3059009062013 SPECIAL SCREW M6X13 WS=8 10.9SPECIAL SCREW M6X13 WS=8 10.9
-
3260010081044 WHEEL SPINDLE REAR CPL.WHEEL SPINDLE REAR CPL.
-
3360010084000 CHAIN TENSIONER R/SCHAIN TENSIONER R/S
-
3460010086000 COLLAR NUT WH. SPINDLE REARCOLLAR NUT WH. SPINDLE REAR
-
3558414030000 HH COLLAR NUT M1OX1,25 WS=13HH COLLAR NUT M1OX1,25 WS=13
-
3650304040000 SPEC. SCREW M10X1.25X40 WS=10SPEC. SCREW M10X1.25X40 WS=10
-
3760010165118 CHAIN 525 WITH MASTER LINKCHAIN 525 WITH MASTER LINK
-
3860010066000 MASTER LINK FOR CHAIN 525MASTER LINK FOR CHAIN 525
