WHEEL - REAR для Polaris OUTLAW 450 S (A09GJ45AA) - 2009 года выпуска
-
№АртикулНазвание
-
15413393 TIRE-REAR, 18X10-9, MX, MAXXISTIRE-REAR, 18X10-9, MX, MAXXIS
-
27542459 NUT, FLANGEDNUT, FLANGED
-
31525017 VALVE, RIMVALVE, RIM
-
41521019 WELD-RIM, 9X8, REAR, AL, VISIONWELD-RIM, 9X8, REAR, AL, VISION
-
57547337 NUT-M18X1.5, CASTLE, ZINC/YELLOWNUT-M18X1.5, CASTLE, ZINC/YELLOW
-
67661404 PIN, COTTERPIN, COTTER
-
77555796 WASHER, CONEWASHER, CONE
-
87555745 WASHERWASHER
-
97515513 STUDSTUD
-
1051356962 HUBHUB
-
111521107 ASM-HUB, REAR (INCL. 9, 10)ASM-HUB, REAR (INCL. 9, 10)
