FRAME - CHASSIS для Polaris 500 CLASSIC (S02ND4BS) - 2002 года выпуска
-
№АртикулНазвание
-
17621453 RIVETRIVET
-
25245003 BRACKET, JACKSHAFT SHIELDBRACKET, JACKSHAFT SHIELD
-
33021104 STOP, TORQUE COURSE 3/8-16STOP, TORQUE COURSE 3/8-16
-
47542404 NUTNUT
-
51013399 WELD, TORQUE STOP FUJIWELD, TORQUE STOP FUJI
-
67517632 SCREWSCREW
-
77517854 SCREWSCREW
-
87517441 SCREWSCREW
-
97621472 RIVETRIVET
-
107512240 BOLTBOLT
-
117552801 LOCK WASHERLOCK WASHER
-
127558301 WASHERWASHER
-
132632165-309 BUMPER (REAR)BUMPER (REAR)
-
145433961-1118 FLAP, SHORT EDGE (BLUE W/WHITE)FLAP, SHORT EDGE (BLUE W/WHITE)
-
152670133 REFLECTOR ASSY. (RED)REFLECTOR ASSY. (RED)
-
162632443-070 ASSY., SNOW SKIRT/REFL (LEFT/BLACK) (INCL. 15)ASSY., SNOW SKIRT/REFL (LEFT/BLACK) (INCL. 15)
-
162632444-070 ASSY., SNOW SKIRT/REFL (RIGHT/BLACK) (INCL. 15)ASSY., SNOW SKIRT/REFL (RIGHT/BLACK) (INCL. 15)
-
175433150 STRAP, RUBBERSTRAP, RUBBER
-
185521238 EXTRUSION, CLUTCHGUARDEXTRUSION, CLUTCHGUARD
-
195245457 MOUNT, CONSOLE TOE CLIP (LEFT)MOUNT, CONSOLE TOE CLIP (LEFT)
-
195245458 MOUNT, CONSOLE TOE CLIP (RIGHT)MOUNT, CONSOLE TOE CLIP (RIGHT)
-
207661637 RIVET, INTERLOCK ZRIVET, INTERLOCK Z
-
215242741 SUPPORT, FOOTREST (LEFT)SUPPORT, FOOTREST (LEFT)
-
215242742 SUPPORT, FOOTREST (RIGHT)SUPPORT, FOOTREST (RIGHT)
-
225245288 FOOTREST (LEFT) ,.080FOOTREST (LEFT) ,.080
-
225242740 FOOTREST (RIGHT)FOOTREST (RIGHT)
-
235245118 BRACE, TUNNEL ROLLBRACE, TUNNEL ROLL
-
242202059 MOUNT, TRAILING ARM KIT (LEFT)MOUNT, TRAILING ARM KIT (LEFT)
-
242202060 MOUNT, TRAILING ARM KIT (RIGHT)MOUNT, TRAILING ARM KIT (RIGHT)
-
255245836 GUARD, BELT EDGE W/BENDGUARD, BELT EDGE W/BEND
-
267080416 PLUG, HOLEPLUG, HOLE
-
277661639 RIVETRIVET
-
285132292 BULKHEAD MACH (FRONT)BULKHEAD MACH (FRONT)
-
294020139 CLIP, PLASTICCLIP, PLASTIC
-
307512275 BOLT, CARRIAGEBOLT, CARRIAGE
-
317670021 SPEED NUTSPEED NUT
-
327555932 WASHER, NYLONWASHER, NYLON
-
337542122 NUT, NYLOCKNUT, NYLOCK
-
331013686-309 ASSY., CHASSIS SVC EDGE NATURALASSY., CHASSIS SVC EDGE NATURAL
