FUEL SYSTEM для Polaris 600 Classic (S06ND6ES) - 2006 года выпуска

№

Артикул

Название
1

7080804 CABLE TIE-RELEASABLE (5 1/2'')

CABLE TIE-RELEASABLE (5 1/2'')

460 ₽
2

2511195-070 CAP ASSY, FUEL (BLACK)

CAP ASSY, FUEL (BLACK)

0 ₽
2

5810512 GASKET

GASKET

2 290 ₽
3

7052095 FITTING, 90 DEG, 1/8

FITTING, 90 DEG, 1/8

750 ₽
4

8450061-600 LINE, FUEL (3MMX7MM)

LINE, FUEL (3MMX7MM)

10 400 ₽
5

7542122 NUT-NYLOK

NUT-NYLOK

110 ₽
6

7555960 WASHER, FLAT

WASHER, FLAT

630 ₽
7

7670021 NUT, SPEED

NUT, SPEED

460 ₽
8

7512193 BOLT, CARRIAGE

BOLT, CARRIAGE

630 ₽
9

5810947 FOAM, SEAL

FOAM, SEAL

460 ₽
10

7052215 PICK-UP, FUEL, W/MESH

PICK-UP, FUEL, W/MESH

6 660 ₽
11

7080768 RING, COMPRESSION

RING, COMPRESSION

1 250 ₽
12

8350020-160 FUEL, LINE (3/8'')

FUEL, LINE (3/8'')

5 620 ₽
13

5435941 GROMMET (3/4'')

GROMMET (3/4'')

1 310 ₽
14

7052269 FITTING (5/16''/ 3/8)

FITTING (5/16''/ 3/8)

3 120 ₽
15

2520289 FUEL TANK ASSY, W/SEND (INCL. 3-10)

FUEL TANK ASSY, W/SEND (INCL. 3-10)

49 920 ₽
16

2410352 SENDER-FUEL, 12 GAL (LEFT)

SENDER-FUEL, 12 GAL (LEFT)

26 000 ₽
17

2410456 PACKAGE-HARDWARE SENDING UNIT

PACKAGE-HARDWARE SENDING UNIT

1 670 ₽
18

8350017-600 FUEL, LINE, ETHER (RED)

FUEL, LINE, ETHER (RED)

0 ₽
19

7080003 CLAMP, HOSE

CLAMP, HOSE

110 ₽
20

1253424 VALVE ASSY, FUEL

VALVE ASSY, FUEL

7 180 ₽
21

8360052-25 TUBING-CONVOLUTED

TUBING-CONVOLUTED

3 750 ₽
22

2520275 PUMP-FUEL, 5/16 IN/OUT, MIK

PUMP-FUEL, 5/16 IN/OUT, MIK

26 000 ₽
23

8450040-600 LINE FUEL (1/4 ID 600 CM.)

LINE FUEL (1/4 ID 600 CM.)

13 520 ₽
