OIL TANK W/ AIR BOX ASSEMBLY для Polaris WIDETRAK LX AND EURO (S07SU4BS/BE) - 2007 года выпуска
-
№АртикулНазвание
-
14040040 SENSOR, OIL LEVEL, W/CONN.SENSOR, OIL LEVEL, W/CONN.
-
25430779 CAP, OIL TANKCAP, OIL TANK
-
35810141 GASKET-OIL CAPGASKET-OIL CAP
-
47558302 WASHER, WROUGHTWASHER, WROUGHT
-
57512276 BOLTBOLT
-
68450003-1525 LINE, FUEL, 1/4 ID (1525 CM.)LINE, FUEL, 1/4 ID (1525 CM.)
-
72530009 FILTER, SMALL, IN-LINE,FILTER, SMALL, IN-LINE,
-
87080307 CLAMP, HOSECLAMP, HOSE
-
97052042 FITTING, OUTLETFITTING, OUTLET
-
107517298 SCREWSCREW
-
117661637 RIVET, INTERLOCK, ZRIVET, INTERLOCK, Z
-
135241792-067 BRKT, SIL./REM.FILLERBRKT, SIL./REM.FILLER
-
147541923 NUT-WELLNUT-WELL
-
157072151 DECALDECAL
-
167552604 WASHERWASHER
-
177512279 SCREWSCREW
-
187542122 NUT-NYLOKNUT-NYLOK
-
195430997 TANK, OILTANK, OIL
-
207670096 NUTNUT
-
217052095 FITTING, 90 DEG, 1/8FITTING, 90 DEG, 1/8
-
228450061-600 LINE, FUEL, 3MMX7MMLINE, FUEL, 3MMX7MM
-
235850075 PLATE, AIR SILENCERPLATE, AIR SILENCER
-
245434015 COVER-SILENCER DRILLED ABSCOVER-SILENCER DRILLED ABS
-
257075359 LABELLABEL
-
264020139 CLIP, ROSEBUDCLIP, ROSEBUD
-
277512222 SCREWSCREW
-
285811688 FOAM-AIRBOX, CHIMNEY, HYBFOAM-AIRBOX, CHIMNEY, HYB
-
297075351 DECALDECAL
-
307073426 DECAL, GREASINGDECAL, GREASING
-
317073820 DECALDECAL
-
321253102 BAFFLE ASM. (INCL. 23)BAFFLE ASM. (INCL. 23)
-
337670055 CLIP, AIR BOXCLIP, AIR BOX
-
345211274 BRACKET, SILENCERBRACKET, SILENCER
-
355432647 SILENCER, INT.MOD, DRILLEDSILENCER, INT.MOD, DRILLED
-
365410403 BOOTBOOT
-
377555843 WASHER, WROUGHTWASHER, WROUGHT
