SUSPENSION/TRACK для Polaris WIDETRAK LX AND EURO (S07SU4BS/BE) - 2007 года выпуска
-
№АртикулНазвание
-
17517731 BOLT, 3/8-16X1.25BOLT, 3/8-16X1.25
-
27556130 WASHER-.406X1.25X.125WASHER-.406X1.25X.125
-
35330171-067 TUBESPACER, CTR, OUTSIDETUBESPACER, CTR, OUTSIDE
-
47041231-067 SPRING, R.EXT, BLACK.SPRING, R.EXT, BLACK.
-
55333014-067 TUBE, CTR.IDLER, BLACK.TUBE, CTR.IDLER, BLACK.
-
65020726 SHAFT, IDLERSHAFT, IDLER
-
77556301 BUSHINGBUSHING
-
81590276-244 ASM-WHEEL IDLER SCRL6.75, SLVASM-WHEEL IDLER SCRL6.75, SLV
-
97621508 RIVET,RIVET,
-
107517247 SCREWSCREW
-
117552603 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
127555806 WASHER, FLATWASHER, FLAT
-
135630399 SPACERSPACER
-
147542439 NUT, NYLOKNUT, NYLOK
-
157555852 WASHER, FLATWASHER, FLAT
-
161590356-244 ASM-WHEEL, 5.62 SCROLL W/IN, SLV (INCL. 20-22)ASM-WHEEL, 5.62 SCROLL W/IN, SLV (INCL. 20-22)
-
175333116 SPACER, WHEELSPACER, WHEEL
-
187553101 WASHER, SPRING LOCKWASHER, SPRING LOCK
-
197517918 BOLT-7/16-14X3.5 HX-Y W/P-80BOLT-7/16-14X3.5 HX-Y W/P-80
-
205431531 INSERT, WHEEL (2 PER WHEEL)INSERT, WHEEL (2 PER WHEEL)
-
217718407 RING-RETAINING (1 PER WHEEL)RING-RETAINING (1 PER WHEEL)
-
223514303 BEARING #6205 (1 PER WHEEL)BEARING #6205 (1 PER WHEEL)
-
237512404 BOLTBOLT
-
245431366 ROLLER, SPRINGROLLER, SPRING
-
257621476 RIVETRIVET
-
265222629 REINF., BUMPERREINF., BUMPER
-
275411682 TRACK-156'' X 20'' X 1'' SHOCKWAVETRACK-156'' X 20'' X 1'' SHOCKWAVE
-
275241473 CLIP, SLIDECLIP, SLIDE
-
287512227 SCREWSCREW
-
291540751 RAIL ASM, LEFT HAND (INCL. 26, 30, 37)RAIL ASM, LEFT HAND (INCL. 26, 30, 37)
-
295521452 SLIDER, WHI., (2)SLIDER, WHI., (2)
-
305430627 COVER-RAIL TIPCOVER-RAIL TIP
-
317621435 RIVETRIVET
-
325132239 SHAFT-PIVOT, .750X13.235SHAFT-PIVOT, .750X13.235
-
337555823 WASHERWASHER
-
341540752 RAIL ASM, RIGHT HAND (INCL. 26, 30, 37)RAIL ASM, RIGHT HAND (INCL. 26, 30, 37)
-
345521452 SLIDER, WHI., (2)SLIDER, WHI., (2)
-
355020720 SHAFT, SPANNERSHAFT, SPANNER
-
367542122 NUT-NYLOKNUT-NYLOK
-
375810554 BUMPER, RAILBUMPER, RAIL
-
385333138 SPACER, R.SHOCKSPACER, R.SHOCK
-
395020651 SHAFT, R.SHOCKSHAFT, R.SHOCK
-
407512659 BOLTBOLT
-
417553201 WASHER, SPLIT LOCKWASHER, SPLIT LOCK
-
427555804 WASHERWASHER
-
435332786 SPACERSPACER
-
441590357 ASM-WHEEL, 5.62 PLAIN W/INSERT (INCL. 20-22)ASM-WHEEL, 5.62 PLAIN W/INSERT (INCL. 20-22)
-
455130570 BRACKET, BOGIE WHEELBRACKET, BOGIE WHEEL
