CARBURETOR - LOWER для Polaris 600 RR EURO (S09MX6FE) - 2009 года выпуска
-
№АртикулНазвание
-
-1203638 ASM-CARB TM 38 600 HO RRASM-CARB TM 38 600 HO RR
-
13130825 SCREWSCREW
-
23131686 ASM-FUNNEL TM38/256-1FASM-FUNNEL TM38/256-1F
-
33130870 O-RING, AIR FUNNELO-RING, AIR FUNNEL
-
53130145 JET, MAIN, HX.HD#450JET, MAIN, HX.HD#450
-
63130859 FLOAT ASM.FLOAT ASM.
-
73131249 JET-AIR, PILOT, 0.6JET-AIR, PILOT, 0.6
-
83131676 DRAIN PLUGDRAIN PLUG
-
93130863 O-RINGO-RING
-
103130824 SCREWSCREW
-
113130858 FLOAT, BODYFLOAT, BODY
-
123130861 O-RINGO-RING
-
133130860 SCREWSCREW
-
143130769 JET, STARTER, #VM11/22-145JET, STARTER, #VM11/22-145
-
153130066 JET, PILOT, #35JET, PILOT, #35
-
163130835 PACKINGPACKING
-
173130837 WASHERWASHER
-
183130836 SPRINGSPRING
-
193130987 ADJUSTERADJUSTER
-
203130986 CAPCAP
-
213130479 CAPCAP
-
227051020 VALVE, CHECK, 90 DEG.VALVE, CHECK, 90 DEG.
