FUEL TANK COVER для Suzuki DR-Z70L8 - 2018 года выпуска
-
№АртикулНазвание
-
144271-14H00-YU1 COVER, FUEL TANK (RH) (YU1 - YELLOW)COVER, FUEL TANK (RH) (YU1 - YELLOW)
-
244281-14H00-YU1 COVER, FUEL TANK (LH) (YU1 - YELLOW)COVER, FUEL TANK (LH) (YU1 - YELLOW)
-
309409-08308-5ES CLIP (BLACK)CLIP (BLACK)
-
401547-0616A BOLTBOLT
-
509169-06081 WASHERWASHER
-
668110-14H20-BLH TAPE SET, FUEL TANK COVER (RH) (BLH - BLUE/WHITE/BLACK/ORANGE/YELLOW)TAPE SET, FUEL TANK COVER (RH) (BLH - BLUE/WHITE/BLACK/ORANGE/YELLOW)
-
768120-14H20-BLH TAPE SET, FUEL TANK COVER (LH) (BLH - BLUE/WHITE/BLACK/ORANGE/YELLOW)TAPE SET, FUEL TANK COVER (LH) (BLH - BLUE/WHITE/BLACK/ORANGE/YELLOW)
