FUEL PUMP для Suzuki VZ1600CA K4 - 2004 года выпуска
-
№АртикулНазвание
-
11060K1106-01929 GASKETGASKET
-
16126K1612-61418 VALVEVALVE
-
32153K3215-31414 PIPEPIPE
-
49040K4904-01074 PUMP-FUELPUMP-FUEL
-
51044K5104-40010 TUBE-ASSYTUBE-ASSY
-
92055K9205-51667 RING-O,14.8X2.4RING-O,14.8X2.4
-
92151K9215-11599 BOLT,5X12BOLT,5X12
-
92170K9217-01492 CLAMPCLAMP
-
92171K9217-11274 CLAMPCLAMP
-
92191K9219-11536 TUBETUBE
-
92191AK9219-11557 TUBETUBE
