TURN SIGNAL ASSY. для Suzuki VZ1600CA K4 - 2004 года выпуска
-
№АртикулНазвание
-
23007K2300-70008 LENS-COMP,SIGNAL LAMP,FRLENS-COMP,SIGNAL LAMP,FR
-
23007AK2300-70009 LENS-COMP,SIGNAL LAMP,RRLENS-COMP,SIGNAL LAMP,RR
-
23007BK2300-70026 LENS-COMP,SIGNAL LAMP,FRLENS-COMP,SIGNAL LAMP,FR
-
23007CK2300-70027 LENS-COMP,SIGNAL LAMP,RRLENS-COMP,SIGNAL LAMP,RR
-
23037K2303-70010 LAMP-ASSY-SIGNAL,FR, LEFT HANDLAMP-ASSY-SIGNAL,FR, LEFT HAND
-
23037AK2303-70011 LAMP-ASSY-SIGNAL,FR, RIGHT HANDLAMP-ASSY-SIGNAL,FR, RIGHT HAND
-
23037BK2303-70012 LAMP-ASSY-SIGNAL,RR, LEFT HANDLAMP-ASSY-SIGNAL,RR, LEFT HAND
-
23037CK2303-70013 LAMP-ASSY-SIGNAL,RR, RIGHT HANDLAMP-ASSY-SIGNAL,RR, RIGHT HAND
-
92002K9200-21607 BOLT,6X20BOLT,6X20
-
92015K9201-51356 NUT,10MMNUT,10MM
-
92022K9202-21302 WASHER,10.5X30X2.3, BLACKWASHER,10.5X30X2.3, BLACK
-
92026K9202-60030 SPACERSPACER
-
92027KK920-27162 COLLAR,6.8X10X12COLLAR,6.8X10X12
-
92069KK920-69063 BULB,12V 21/5WBULB,12V 21/5W
-
92172K9217-20118 SCREW,TAPPING,4X10SCREW,TAPPING,4X10
-
92210K9221-00141 NUT,CAP,6MMNUT,CAP,6MM
