FUEL TANK для Yamaha XV 1600 A ROAD STAR - 2003 года выпуска
-
№АртикулНазвание
-
14WM-Y2410-31-W3 FUEL TANK COMP. (DARK VIOLET METALLIC (DVMA) / VERY DARK BLUE METALLIC (VDBMA)FUEL TANK COMP. (DARK VIOLET METALLIC (DVMA) / VERY DARK BLUE METALLIC (VDBMA)
-
14WM-Y2410-31-W4 FUEL TANK COMP. (SILVER (S3) / GRACEFUL MAROON (GRM)FUEL TANK COMP. (SILVER (S3) / GRACEFUL MAROON (GRM)
-
14WM-YK241-31-P4 FUEL TANK COMP. ( VERY DARK ORANGE METALLIC (VDOM1))FUEL TANK COMP. ( VERY DARK ORANGE METALLIC (VDOM1))
-
25GA-24240-50-00 ...GRAPHIC SET (FOR DARK VIOLET METALLIC (DVMA))...GRAPHIC SET (FOR DARK VIOLET METALLIC (DVMA))
-
24WM-24240-B0-00 ...GRAPHIC SET (FOR SILVER (S3))...GRAPHIC SET (FOR SILVER (S3))
-
32YK-24181-10-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
45MB-24191-00-00 BRACKET, FUEL TANK 1BRACKET, FUEL TANK 1
-
55MB-24192-00-00 BRACKET, FUEL TANK 2BRACKET, FUEL TANK 2
-
65MB-24181-00-00 DAMPER, LOCATING 1DAMPER, LOCATING 1
-
75MB-24182-00-00 DAMPER, LOCATING 2DAMPER, LOCATING 2
-
85MB-24183-00-00 DAMPER, LOCATING 3DAMPER, LOCATING 3
-
95MB-24186-00-00 WASHER, SPECIALWASHER, SPECIAL
-
102GH-24186-00-00 WASHER, SPECIALWASHER, SPECIAL
-
1190387-06062-00 COLLARCOLLAR
-
1292017-06035-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
1395827-06140-00 BOLT, FLANGEBOLT, FLANGE
-
1490201-064R0-00 WASHER, PLATEWASHER, PLATE
-
1590176-06055-00 NUT, CROWNNUT, CROWN
-
1690387-06061-00 COLLARCOLLAR
-
174WM-24291-00-00 BRACKET, FUEL TANK 1BRACKET, FUEL TANK 1
-
184WM-24339-00-00 GROMMETGROMMET
-
1990387-050T5-00 COLLARCOLLAR
-
2095707-05500-00 NUT, FLANGENUT, FLANGE
-
214WM-24500-00-00 FUEL COCK ASSY 1FUEL COCK ASSY 1
-
223AJ-24523-00-00 ...VALVE PACKING...VALVE PACKING
-
233AJ-24534-00-00 ...SEAL, COCK...SEAL, COCK
-
2497801-03008-00 ...SCREW, PAN HEAD...SCREW, PAN HEAD
-
254X8-24512-00-00 ...O-RING...O-RING
-
2690202-05193-00 WASHER, PLATEWASHER, PLATE
-
2790149-06011-00 SCREWSCREW
-
284WM-24311-00-00 PIPE, FUEL 1PIPE, FUEL 1
-
294WM-24393-00-00 SPRINGSPRING
-
3090467-13083-00 CLIPCLIP
-
311FK-24560-10-00 FILTER ASSYFILTER ASSY
-
324WM-24312-00-00 PIPE 2PIPE 2
-
334WM-24394-00-00 SPRINGSPRING
-
344WM-24398-00-00 BAND 1BAND 1
-
354WM-24217-00-00 COVERCOVER
-
364NK-24602-10-00 CAP ASSYCAP ASSY
-
374WM-24321-00-00 PIPE 10 (EXCEPT CALIF)PIPE 10 (EXCEPT CALIF)
-
374WM-24321-10-00 PIPE 10 (CALIF ONLY)PIPE 10 (CALIF ONLY)
-
3890467-10041-00 CLIPCLIP
-
3990464-15192-00 CLAMP (CALIF ONLY)CLAMP (CALIF ONLY)
-
4090464-25217-00 CLAMPCLAMP
-
414WM-24180-00-00 ROLL OVER VALVE ASSYROLL OVER VALVE ASSY
-
4290461-15100-00 CLAMPCLAMP
-
434WM-2148X-00-00 BRACKET 4 (CALIF ONLY)BRACKET 4 (CALIF ONLY)
-
4498507-05008-00 SCREW, PAN HEAD (CALIF ONLY)SCREW, PAN HEAD (CALIF ONLY)
-
4598907-05012-00 SCREW, BINDSCREW, BIND
-
464WM-24662-00-00 STAY (CALIF ONLY)STAY (CALIF ONLY)
-
4790445-112K5-00 HOSE (L355) (EXCEPT CALIF)HOSE (L355) (EXCEPT CALIF)
-
474WM-24322-00-00 PIPE 11 (CALIF ONLY)PIPE 11 (CALIF ONLY)
-
484WM-24323-00-00 PIPE 12 (CALIF ONLY)PIPE 12 (CALIF ONLY)
-
4990467-10041-00 CLIP (EXCEPT CALIF)CLIP (EXCEPT CALIF)
-
504XY-14568-00-00 JOINT (CALIF ONLY)JOINT (CALIF ONLY)
-
5190464-15192-00 CLAMP (CALIF ONLY)CLAMP (CALIF ONLY)
-
5290464-09M31-00 CLAMP (CALIF ONLY)CLAMP (CALIF ONLY)
-
534WM-24170-00-00 CANISTER ASSY (CALIF ONLY)CANISTER ASSY (CALIF ONLY)
-
544WM-2419E-00-00 COVER, CANISTER (CALIF ONLY)COVER, CANISTER (CALIF ONLY)
-
5590105-06009-00 BOLT, FLANGE (CALIF ONLY)BOLT, FLANGE (CALIF ONLY)
-
5690467-10041-00 CLIP (CALIF ONLY)CLIP (CALIF ONLY)
-
5690467-10041-00 CLIP (CALIF ONLY)CLIP (CALIF ONLY)
-
574GY-24188-00-00 MOLD, FUEL TANKMOLD, FUEL TANK
-
584WM-24491-01-00 BRACKET, FUEL PUMPBRACKET, FUEL PUMP
-
5995807-06016-00 BOLT, FLANGEBOLT, FLANGE
-
604WM-2416B-00-00 EMBLEMEMBLEM
-
614WM-2417B-00-00 EMBLEMEMBLEM
-
624WM-13907-00-00 FUEL PUMP COMP.FUEL PUMP COMP.
-
6390464-13249-00 CLAMPCLAMP
