SIDE COVER для Yamaha R6 (2C0F/2C0G) [YZFR6W/C] - 2007 года выпуска
-
№АртикулНазвание
-
12C0-21710-00-P0 SIDE COVER ASSY 1 (OPT) (DPBMC)SIDE COVER ASSY 1 (OPT) (DPBMC)
-
12C0-21710-00-P4 SIDE COVER ASSY 1 (OPT) (DRMK)SIDE COVER ASSY 1 (OPT) (DRMK)
-
12C0-21710-00-P5 SIDE COVER ASSY 1 (OPT) (DBNM8)SIDE COVER ASSY 1 (OPT) (DBNM8)
-
25PW-2174X-00-00 ...DAMPER...DAMPER
-
390183-05076-00 ...NUT, SPRING...NUT, SPRING
-
44KN-2836B-00-00 ...TUNING FORK MARK...TUNING FORK MARK
-
52C0-21747-00-00 ...DAMPER...DAMPER
-
62C0-2172P-00-00 ...SEAT...SEAT
-
72C0-2173P-00-00 ...SEAT...SEAT
-
85SL-84753-00-00 ...DAMPER...DAMPER
-
990111-05003-00 BOLT, HEX. SOCKET BUTTONBOLT, HEX. SOCKET BUTTON
-
1090202-05180-00 WASHER, PLATEWASHER, PLATE
-
1190269-07076-00 RIVETRIVET
-
1290269-06001-00 RIVETRIVET
-
1390183-05076-00 NUT, SPRINGNUT, SPRING
