THUMB/GRIP WARMER KIT для Yamaha BRAVO 250 - 2000 года выпуска
-
№АртикулНазвание
-
18BD-W8293-00-00 THUMB/GRIP WARMER KIT (AP)THUMB/GRIP WARMER KIT (AP)
-
28AU-82970-01-00 ...THUMB WARMER ASSEMBLY...THUMB WARMER ASSEMBLY
-
397706-30620-00 ...SCREW, TAPPING...SCREW, TAPPING
-
497707-30630-00 ...SCREW, TAPPING...SCREW, TAPPING
-
588T-26240-00-00 ...GRIP ASSEMBLY...GRIP ASSEMBLY
-
690267-40076-00 ...RIVET, BLIND...RIVET, BLIND
-
78BD-82318-00-00 ...WIRE, SUB-LEAD...WIRE, SUB-LEAD
-
88BE-82917-00-00 ...SWITCH (ALTERNATE ELECTRICAL)...SWITCH (ALTERNATE ELECTRICAL)
Все узлы модели:
- AIR INTAKE W/ INTAKE
- AIR SHROUD W/ FAN
- BRAKE ASSY
- BUMPER - FRONT AND REAR
- CARBURETOR ASSY
- CHAINCASE ASSY
- CLUTCH - DRIVE
- CLUTCH - DRIVEN W/ DRIVE AXLE
- CLUTCH REPAIR KIT
- CLUTCH TUNE-UP KIT
- CONSOLE ASSY
- CRANKCASE ASSY
- CRANKSHAFT W/ PISTON ASSY
- CYLINDER W/ HEAD ASSY
- DECALS
- DRIVE TRAIN ASSEMBLY
- ELECTRICAL - COIL, CDI, RECTIFIER, RELAYS AND SWITCHES
- ELECTRICAL - HEADLIGHT ASSY
- ELECTRICAL - INSTRUMENTS
- ELECTRICAL - MAGNETO ASSEMBLY
- ELECTRICAL - TAILLIGHT ASSY
- ENGINE MOUNTING
- EXHAUST SYSTEM
- FUEL TANK 1
- FUEL TANK 2
- GUARD - LUGGAGE BOX
- HANDLE SWITCH - LEVER
- HANDLEBAR - CABLES AND GRIPS
- HANDLEBAR ASSY W/ STEERING ASSY
- HANDLEBAR PAD W/ STEERING GATE
- OIL PUMP ASSY
- OIL PUMP DRIVE GEAR
- OIL TANK ASSY
- REAR VIEW MIRROR SET
- REFLECTOR ASSY
- SEAT ASSY
- SHROUD WINDSHIELD
- STARTER - RECOIL
- SUSPENSION - FRONT W/ SKI ASSY
- SUSPENSION - IDLER WHEELS W/ RAIL ASSY - TRACK
- SUSPENSION - TORQUE ARM ASSY
- • THUMB/GRIP WARMER KIT
- TUNNEL ASSEMBLY W/ LOWER NOSEPAN
